EN DESCRIPTION
Sensors, buttons and indicators
Duct out + Recirculation (DR)
B
Sensor panel – sensors, buttons and indicators
1 Air quality sensor, intake.
2 Air quality sensor, exhaust.
3 Stove monitoring sensor.
4 Fan speed indicator: Lights up white when the fan is running.
Speed 1–4, Boost.
In Boost mode: Constantly flashing all indicator lights.
5 Auto indicator: Lights up white when the fan is running
automatically.
Off when lighting and fan speed are changed manually via
push of a button.
6 Lamp button: Pressing the button switches the lighting on/
off.
Pressing the button turns off the automatic light control.
Hold down the button: Cycle between the presets defined in
the smartphone App.
7 Plus button: Increases the fan speed. Pressing the button
turns off the automatic ventilation.
Hold down the button: Activates Boost (runs for 9 minutes.
70
1 2 3
10 9
8 Minus button: Reduces the fan speed alternatively
deactivates Boost. Pressing the button turns off the
automatic ventilation.
When deactivating Boost: The fan speed jumps back to the
level that was present before the boost mode.
9 OK button: Start bluetooth pairing.
In the event of a stove alarm: Dismiss the alarm.
Product equipped with a Power Control Unit (PCU): Test the
system.
10 OK indicator
See separate section.
4 5
8 7 6
