- Page 1 OWNER’S MANUAL Please, read this manual carefully before use! Inverter Generator KSB 12i S...
-
Page 2: Safety Information
INTRODUCTION Thank you for your purchase of K&S Basic products. This manual contains a brief description of safety, use ® and debugging. More information can be found on the official manufacturer’s website in the support section: koenner-soehnen.com/manuals You can also go to the support section and download the full version of the manual by scanning the QR code, or on the website of the official importer of K&S Basic products: koenner-soehnen.com ®... -
Page 3: Main Overview
Further details regarding the use of the generator in IT and TN systems can be found on our website or requested from our technical support. Wires with damaged or spoiled insulation should be replaced. You should also replace worn, damaged or rusty contacts. Be careful. -
Page 4: Specifications
SPECIFICATIONS Model KSB 12i S Voltage, V Max Power, kW Nominal Power, kW Frequency, Hz Current, A (max.) Outlets 1*16А Engine start manual Fuel tank volume, l Noise level L (7m)/L , dB 62/87 Output 12V, A 12V/5A USB-Outputs 5V/1A, 5V/2.1A... -
Page 5: Working With The Device
WORKING WITH THE DEVICE OIL LEVEL INDICATOR OIL LEVEL INDICATOR When the oil level falls below the level required for operation, the oil level indicator lights up, and then the engine stops automatically. The engine will not start until oil is added. AC AC INDICATOR INDICATOR When the generator is running and producing electricity, the AC indicator light is on. -
Page 6: Before Starting
BEFORE STARTING CHECK THE FUEL LEVEL CHECK THE FUEL LEVEL 1. Unscrew the fuel cap and check the fuel level in the tank. 2. Fill the fuel tank to the fuel filter level. 3. Tighten the fuel cap securely. Immediately wipe off spilled fuel with a clean, dry, soft cloth, since fuel may deteriorate painted surfaces or plastic parts. - Page 7 IN THE FIRST 20 OPERATING HOURS OF THE GENERATOR, THE FOLLOWING REQUIREMENTS SHOULD BE MET: IN THE FIRST 20 OPERATING HOURS OF THE GENERATOR, THE FOLLOWING REQUIREMENTS SHOULD BE MET: 1. During commissioning, do not connect power consumers, the power of which exceeds 50% of the nominal (operating) power of the device.
- Page 8 FUNCTIONAL DESCRIPTION OF INVERTER GENERATORS ECON FUNCTION ECON FUNCTION 1. Start the engine. 2. Set the ECON switch to “ON”. 3. Plug the device into an AC outlet. 4. Make sure the AC indicator light is on. 5. Turn on the electrical device. The ECON switch must be set to “OFF”...
-
Page 9: Recommended Oils
MANUAL COMPLIANCE Technical maintanance, operation and TM K&S Basic generator storage are to be performed according to this manual recommen- IMPORTANT! dations. Manufacturer bears no responsibility for damages and losses, caused by incompliance to safety requirements and tech- nical maintanance rules. TECHNICAL MAINTENANCE WORKS Level check Motor oil... - Page 10 fill to here REPLACING OR ADDING MOTOR OIL: REPLACING OR ADDING MOTOR OIL: Upon oil level decrease it is necessary to add the required quantity in order to provide the correct generator operation. It is necessary to check the oil levels according to technical maintanance schedule.
-
Page 11: Generator Storage
SPARK PLUG INSPECTION: SPARK PLUG INSPECTION: Spark plug 1. Remove the cap from the spark plug. 2. Remove the spark plug by means of a corresponding spanner. 3. Examine the spark plug. If it is shattered – it is necessary to replace it. Recommended replacement spark plugs –... - Page 12 - Pull the manual starter until a slight resistance is felt so that the inlet and drain valves get closed. - Clean the generator from dirt and dust. When starting the generator after long-term storage, proceed as above in the reverse order. GENERATOR TRANSPORTATION For easy generator transportation use packaging, which generator was sold in.
