Chisel Plow
Mounted Models: CPP7-02 through CPP12-02
and CPP7-03 through CPP12-03
Operator's Manual
LANDOLL CORPORATION
1900 North Street
Marysville, Kansas 66508
(785) 562-5381
800-428-5655 ~ WWW.LANDOLL.COM
175rev1113
7D525

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPP-7 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brillion CPP-7 Series

Summary of Contents for Brillion CPP-7 Series

  • Page 1 Chisel Plow Mounted Models: CPP7-02 through CPP12-02 and CPP7-03 through CPP12-03 Operator’s Manual LANDOLL CORPORATION 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM 175rev1113 7D525...

  • Page 3: Table Of Contents

    Table of Contents Introduction and Safety Information Introduction ..............1-1 Description of Unit .

  • Page 5: Introduction And Safety Information

    Proper assembly and products. Your implement’s parts should only be replaced maintenance will provide you with satisfactory use for with Brillion parts. If items covered in this manual are not seasons to come. understood, contact your local Brillion Dealer.

  • Page 6: Safety

    Examine safety decals and be sure you have the correct safety decals for the implement. See Figure 1-2. Attaching, Detaching and Storage Order replacement decals through your Brillion dealer. • Do not stand between the tractor and implement when Keep these signs clean so they can be observed readily.

  • Page 7: Maintenance Safety

    INTRODUCTION AND SAFETY INFORMATION Maintenance Safety • Because prolonged exposure to loud noise can cause hearing impairment or hearing loss, wear suitable • Block the implement so it will not roll when working on hearing protection, such as earmuffs or earplugs. or under it to prevent injury.

  • Page 8: Decals

    INTRODUCTION AND SAFETY INFORMATION Decals Figure 1-2: Decals and Locations 7D525...

  • Page 9: Assembly

    Chapter 2 Assembly Gage Wheels  CAUTION Figure 3 shows how the gage wheels are assembled to Do not work on or under this machine unless the frame, if your is so equipped. securely blocked and supported by a hoist or To adjust gage wheel, loosen the four 5/8 x 3”...

  • Page 10: Frame Assembly Dimensions

    ASSEMBLY Frame Assembly Dimensions “Left” and “Right” refer to directions seen as if standing behind the machine and facing in the direction of forward travel. Figure 2-1: Frame Assembly Dimensions Frame Shank Category Dimension Dimension Assembly Size Used “A” “B” 32-3/8”...

  • Page 11: Mast

    ASSEMBLY Mast Figure 2-2: Mast The rigid mounted shanks are shipped assembled to the Tighten all nuts. Mount the assembly to the toothbar. shank clamps. To mount these on the chisel plow, Torque the 3/4” nuts to 200 ft. lbs. remove the 3/4”...
  • Page 12 ASSEMBLY Figure 2-3: Rigid and Spring Clamp 7D525...

  • Page 13: Assembly Of Chisel Plows

    ASSEMBLY Assembly of Chisel Plows After the basic 7 foot frame is assembled for the 9 foot and 11 foot or the basic 10 foot frame for the 12 foot models. Then add on the extensions as illustrated in the following pages.
  • Page 14 ASSEMBLY To make 9 foot and 12 foot machines the one foot To assemble an 11 foot machine, bolt a two foot extension is assembled to the basic 7 foot or 10 foot extension to each side of the main frame as shown in machine.

  • Page 15: Twisted Shovels

    ASSEMBLY Twisted Shovels If twisted shovels are to be used, it is suggested that they be arranged on the shanks as shown in Figure 2-7. (L.H. means that the soil is thrown left and R.H. means that the soil is thrown to the right.) If another arrangement is desired, be sure that the shovels have balanced positions from right side to left;...
  • Page 16 ASSEMBLY Figure 2-7: 7 Shank Mounting Dimensions 7D525...
  • Page 17 ASSEMBLY Figure 2-8: 9 Shank Mounting Dimensions...
  • Page 18 ASSEMBLY Figure 2-9: 10 Shank Mounting Dimensions 2-10 7D525...
  • Page 19 ASSEMBLY Figure 2-10: 11 Shank Mounting Dimensions 2-11...
  • Page 20 ASSEMBLY Figure 2-11: 12 Shank Mounting Dimensions 2-12 7D525...

  • Page 21: Led Warning Lights

    ASSEMBLY LED Warning Lights Figure 2-12: LED Warning Lights 2-13...
  • Page 22 ASSEMBLY Figure 2-13: Electrical Installation Dimensions 2-14 7D525...
  • Page 23 ASSEMBLY Figure 2-14: 7’ and 9’ LED Warning Lights Layout 2-15...
  • Page 24 ASSEMBLY Figure 2-15: 10’ and 12’ LED Warning Lights Layout 2-16 7D525...
  • Page 25 ASSEMBLY Figure 2-16: 11’ LED Warning Lights Layout 2-17...

  • Page 26: Led Installation Instructions

    ASSEMBLY LED Installation Instructions All wires must be firmly attached to machine frame members so they do not sag or become torn loose by field debris. NOTE All models similar. Refer to Figure 2-13 for bracket and light placement. 1. Attach the 2 (two) Light Brackets to the rear frame using the 1/2-13 U-Bolts and Nuts.

  • Page 27: Operation

    This chapter will cover the basic operation and Before operating your Brillion machine, check all procedures for the Landoll Brillion Chisel Plow. Be sure to hardware for tightness. Use the Tightening Torque Table read and understand the Safety Procedures and in Chapter 4 as a guide.
  • Page 28 OPERATION Table provided for general use. NOTES: 7D525...

  • Page 29: Maintenance

    Chapter 4 Maintenance General Torque Specifications (rev. 4/97) This chart provides tightening torques for general purpose applications when special torques are not specified on process or drawing. Assembly torques apply to plated nuts and capscrews assembled without supplemental lubrication (as received condition). They do not apply if special graphite moly-disulfide or other extreme pressure lubricants are used.

  • Page 30: Fasteners

    MAINTENANCE Fasteners Before operating your Brillion machine, check all hardware for tightness. Use the Tightening Torque Table below as a guide. See Page 4-1. After a few hours of use, check entire machine and tighten any loose nuts or bolts. Daily or periodic checks should be made thereafter.

  • Page 31: General Reference And Specifications

    Chapter 5 General Reference and Specifications General Working Depth.............0 to 12” Shanks.........1” x 2” x 26” Clearance Gage Wheel Rims..........15” - 5 Bolt 1 1/4” x 2” x 32” Clearance Shank Spacing..........One Foot Model Number Number of Shanks 3 Point Lift CPP-7 CAT.
  • Page 32 GENERAL REFERENCE AND SPECIFICATIONS Table provided for general use. NOTES: 7D525...
  • Page 33 Document Control Revision Log: Date Revision Improvement(s) Description and Comments 07/2001 Initial Release 11/2013 175rev1113 Updated to the Landoll format. Added LED Warning Lights...
  • Page 34 Equipment from Landoll Corporation is built to exacting standards ensured by ISO 9001 registration at all Landoll manufacturing facilities. Chisel Plow Mounted Models: CPP7-02 through CPP12-02 and CPP7-03 through CPP12-03 Operator’s Manual Re-Order Part Number 7D525 LANDOLL CORPORATION 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM...
