- Page 1 OPERATOR’S MANUAL REPAIR PARTS CATALOG Floating Ring Pulverizer Pick-up Model: PPF BRILLION IRON WORKS, INC. BRILLION FARM EQUIPMENT 1199rev401 BRILLION, WISCONSIN 54110 6K107 www.brillionfarmeq.com 1199rev401 6K107...
- Page 2 1199rev401 6K107...
-
Page 3: Table Of Contents
FLOATING RING PULVERIZERS CONTENTS PART I - OPERATION Introduction ............................... 3 Location Reference ........................3 Parts Ordering ..........................3 Safety Suggestions ........................... 4 Safety Sign Description and Illustration ..................4 Decal Location ..........................5 Machine Specifications ..........................6 Operating Instructions ..........................7 Stand Positioning ......................... - Page 4 1199rev401 6K107...
-
Page 5: Introduction
To obtain maximum benefits from the FLOATING RING PICKUP PULVERIZER, please study this manual carefully before starting assembly or operation. A special section, “Assembly Instructions”, is included. If items in this manual are not understood, contact your local BRILLION dealer or call BRILLION IRON WORKS, INC., at (920) 756-3720. -
Page 6: Safety Suggestions
SAFETY SUGGESTIONS Investigation has shown that nearly one-third of all farm accidents are caused by careless use of machinery. You can do your part in improving safety by observing the following suggestions. Insist that all people working with you or for you abide by them. 1. -
Page 7: Decal Location
DECALS & LOCATIONS Figure 2B 1. 8J309 - Decal, “Caution” list 2. 2J431 - Decal, Reflective Amber 3. 2J430 - Decal, Reflective Red 4. 4K103 - Decal “BRILLION” 6’ & 8’ MODELS 10’ - 18’ MODELS Page 5 1199rev401 6K107... -
Page 8: Machine Specifications
SPECIFICATIONS Subject to change due to product improvement Model Designation Basic model is denoted by: PPF= Pickup Pulverizer with Floating ring wheels Numbers following indicate machine widths in feet: 6’, 8’, 10', 12', 14', & 16' wide Letter following indicates wheel size: B=4K392;... -
Page 9: Operating Instructions
OPERATIING INSTRUCTIONS Securely block machine when working on or under it to prevent injury in case of hydraulic failure or inadvertent lowering by another person. 1. Stand Postion OPERATING POSITION Figure 3 When operating, keep support stand locked up in raised position. PARKED POSITION To park the pulverizer, lower it to a firm, level surface, then set and fix the support... -
Page 10: Attaching Tractors To Pulverizers
2. Attaching Tractors to Pulverizers This pulverizer is designed to be mounted to tractors with a category II or a Category III 3-point hitch. Instructions for attachment are as follows: With Category II Hitch See Figure 4. Use the lower set of holes for the tractor lift arms to provide maximum transport clearance. (Upper holes are for other model machines). -
Page 11: Category Iii Hitch
With Category III Hitch See Figure 5. Use the lower set of holes for the tractor lift arms to provide maximum transport clearance. (Upper holes are for other model machines). Install lower hitch pins with cast iron spacers inside of machine and 1-7/16" O.D. sleeves toward outside. -
Page 12: Field Operation
Field Operation The floating ring pulverizer is designed with rings whose inside diameter is two to four inches greater than the drum which supports them. This allows the packer wheels to follow the irregular contours in your fields. 2”- 4” FIGURE 6 WHEEL INSIDE DIA. -
Page 13: Replacing Or Adding Rollers
REPLACING OR ADDING ROLLER WHEELS Although the packer wheels are manufactured from high grade ductile iron, wear or breakage may require that some wheels be periodically replaced. Follow these steps when replacing wheels. 1. Attach a tractor to the pulverizer, put the tractor transmission into PARK, and lock the brakes on FIGURE 8 the tractor. - Page 14 WARNING LIGHT ASSEMBLY #4K774 ANGLE #3J662 STRAP, 5” TUBE #4K773 R.H. LAMP #4K970 STRAP, 7” TUBE ASSEMBLY (SHOWN) #6J150 LOCKNUT, 1/4” #4K772 L.H. LAMP ASSEMBLY (NOT SHOWN) REAR #1C675 BOLT, 6” #4K937 BOLT, 8 1/2:” #1C109 LOCKWASHER #1C390 HEX NUT, 1/2” #4K782 MACHINE SCREW 1/4”...
-
Page 15: Warning Lights
REPAIR PARTS CONTENTS Frame ............................14 Roller ............................16 Roller Assemblies ........................18 Warning Lights ......................... 19 Index ............................20 Page 13 1199rev401 6K107... - Page 16 CAUTION MOVING MACHINES CAN CAUSE INJURY. KEEP AWAY! 1. DO NOT STAND OR WALK IN FRONT OF TRACTOR WHEN IT IS MOVING FORWARD. 2. DO NOT STAND OR WALK BETWEEN TRACTOR & IMPLEMENT WHEN EITHER OR BOTH ARE MOVING. 3. DO NOT STAND OR WALK BEHIND IMPLEMENT WHEN IT IS BEING BACKED UP.
-
Page 17: Frame
Sleeve, 1 1/4” O.D. x 1 15/16” 8D922 Capscrew, 1” x 4 1/2” 1.24 6D306 Lock Nut, 1” 6D988 Pipe Spacer, 1” x 2 1/8” 8D424 Pin Assembly 8D425 Cast Iron Spacer 1.60 5D158 Sleeve, 1 7/16” O.D. 4K103 Decal, “Brillion” Page 15 1199rev401 6K107... - Page 18 1199rev401 6K107 Page 16...
-
Page 19: Roller
ROLLER Index Part Description Req’d 5K769 Bearing Support 24.80 4K993 Pillow Block Bearing with Collar 6.63 5J912 Bolt, 5/8-11 NC x 9 1/2” Long (10’ - 16’ Machines) 2.86 6D303 Bolt, 5/8-11 NC x 7 1/2” Long (6’ & 8’ Machines) 5C461 Lock Nut, 5/8-11 Hex 1D445... -
Page 20: Roller Assemblies
LENGTH WHEEL DIAMETER DRUM DIAMETER ROLLER ASSEMBLIES Assembly Drum (Pipe) Wheel Dia. Length Used on Roller Diameter (In inches) (In feet) Pulv. Model # Assem. Wt.(#) 5K810 12” Pipe PPF6B12 1288 5K809 12” Pipe PPF8B12 1678 5K066 12” Pipe PPF10B12 2068 5K067 12”... -
Page 21: Warning Lights
2, 3 4K938 WARNING LIGHT KIT Index Part Description Req’d 4K774 Angle 7.70 4K772 Dual Lamp, L.H. 2.00 4K773 Dual Lamp, R.H. 2.00 4K828 Wishbone Harness, 15’ (not shown) 3.00 4K936 Ag. Harness, 10’ (not shown) 2.00 4K937 Machine Bolt, 1/2” x 8 1/2” 1C109 Lock Washer, 1/2”... -
Page 22: Index
INDEX Part Index Part Index Part Index Page Page Page 4K990 1B166 4K991 4K993 4K993 1C392 5K031 3C335 5K032 5C461 5K033 5C461 5K034 6C400 5K035 6C729 5K066 5K067 5K068 1D445 5K069 1D445 5K070 3D510 5K196 5D110 5K196 5D157 5K766 5D158 5K769 6D049 5K769... - Page 24 Equipment from Landoll Corporation is built to exacting standards ensured by ISO 9001 registration at all Landoll manufacturing facilities. LANDOLL CORPORATION 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM Copyright 2010. Landoll Corporation "All rights reserved, including the right to reproduce this material or portions thereof in any form" 6K107...
