EU-297
The room regulator should be connected to the heating device with a two-core cable. The cable connection of both
devices is shown in the diagram below:
NOTE
The regulator is powered with batteries - it is recommended to check the batteries from time to time and replace
them once every heating season.
2.
INSTALLATION OF THE REGULATOR – POWER SUPPLY 230V
The room regulator may be used as a wall-mountable panel. In order to mount it, place the rear part of the controller in
the mounting box on the wall, insert the regulator and turn it slightly.
heating
device
7
