- Page 1 Assembly Instructions Double or King Size Super King Size @ h a p p yb e d s www . h a p py b e d s . c o . u k @ h a p p y b e d s...
- Page 2 No: We're so sorry to here this! Please contact us by scanning the QR code or visit us at www.happybeds.co.uk/customer-service and someone will be happy to help. w w w . h a p p y b e d s . c o . u k...
- Page 3 Don't miss out! Sign up to our newsletter so you don't miss out on our amazing sales and giveaways! Head to our website, www.happybeds.co.uk to sign up and save £10 off your next order. Your chance to WIN some luxury sleep products...
- Page 4 w w w . h a p p y b e d s . c o . u k @ h a p p yb e d s...
-
Page 5: Health And Safety
Health & Safety: This product or some parts of this product will be heavy. Please use an assistant when lifting. Please keep small parts out of reach of children. Always use on a level, even surface. DO NOT jump on the product or any of its parts. DO NOT use this product if any parts are missing, damaged or worn. - Page 6 No Part List No Part List Headboard 1 pc 1 pc Metal slat frame for double or king size Footboard 1 pc Mattress stoppers 2 pcs 2 pc Gas lift pistons 2 pcs Side rails Fabric base cover 1 pc Fabric hand strap 1 pc “U”...
- Page 7 HARDWARE NEEDED FOR BED ASSEMBLY (PACK A) Hardware List Hardware List Bolt (M8x35mm) for fitting Allen key for 1 pc 12 pcs side rail hook brackets to M6 bolts headboard & footboard Allen key for Spring washer for 1 pc 24 pcs M8 bolts M8 bolts...
- Page 8 Step 1: Bolts (M8x35mm) 12 pcs Spring Washer for 24 pcs M8 bolts Flat Washer for 24 pcs M8 bolts Bolts (M8x20mm) 12 pcs Allen key for 1 pc M8 bolts 2 pcs Hook Bracket - LH 2 pcs Hook Bracket - RH Step 2: Spring Washer for Allen key for...
- Page 9 Note: depending on your purchase, please use this hardware for: Step 3a: (3a) Su u p p e e r r King size - or for (3b) D D ouble & King size. Flat Washer for Spring Washer for 12 pcs 12 pcs M6 bolts M6 bolts...
- Page 10 Note: depending on your purchase, please use this hardware for: Step 4a: (4a) Su u p p e e r r K K ing size - or for (4b) Do o u u b b l l e e & K ing size. Flat Washer for Footboard Bolts 4 pcs...
- Page 11 Step 5: Lift and turn bed on its side and with assistant holding bed upright for safety, attach fabric base cover (4) using the velcro tape, to bottom of side-rails, headboard & footboard. Make sure fabric is fixed evenly all round. Spring Washer for Step 6: 4 pcs...
- Page 12 Step 7: Connect mains power lead (15) to your wall socket - for safety this must be an earthed power supply. Step 8: Press the “UP” button to raise the TV lift. Page 12 of 18...
- Page 13 Note: For illustration purposes only, TV connections may vary. Step 9: Media Cable are not supplied Tip: Before fitting the TV, push cables through each duct from the top choosing the best side to use depending on where the connection ports are on back of your TV.
- Page 14 Step 11: If the TV is supplied with Vesa bolts and spacers, please use those in preference to those provided Check the hardware supplied with the TV BRACKET television and if Vesa bolts and spacers are supplied please use these to fit the TV. When spacers are provided it is very important that these are fitted in the correct place, fit between TV...
- Page 15 Note: For illustration purposes only, TV connections may vary. Step 13: TV Power Lead Keep all leads tight, peel supplied with your TV off cover from cable clips & adhere to back of TV. 17 7 18 8 KEEP ALL CABLES TIGHT BY USING CLIPS &...
- Page 16 N N o o t t e e : : P P l l e e a a s s e e c c h h o o o o s s e e w w h h i i c c h h s s i i d d e e o o f f t t h h e e s s l l a a t t f f r r a a m m e e t t o o l l i i f f t t u u p p t t o o r r e e a a c c h h i i n n t t o o t t h h e e s s t t o o r r a a g g e e a a r r e e a a Step 15a: t t h h e e n n , , d d e e p p e e n n d d i i n n g g o o n n y y o o u u r r p p u u r r c c h h a a s s e e , , p p l l e e a a s s e e u u s s e e t t h h i i s s h h a a r r d d w w a a r r e e f f o o r r t t h h e e D D o o u u b b l l e e , , K K i i n n g g o o r r S S u u p p e e r r K K i i n n g g s s i i z z e e b b e e d d : : ( ( 1 1 5 5 a a ) ) l l i i f f t t f f r r o o m m L L E E F F T T O O R R ( ( 1 1 5 5 b b ) ) L L I I F F T T F F R R O O M M R R I I G G H H T T .
- Page 17 Step 16: Allen Key for 1 pc M8 bolts Spanner for flanged 1 pc M8 lock-nuts Carefully lay frame down. Make sure there is an even gap each side of about 8 mm, as in the sketch. Hold frame securely then tighten all six bolt sets 100% using spanner (R) &...
-
Page 18: General Care And Maintenance
floor as this will cause damage to the joints and could result in failure to the product that will invalidate the warranty. For more information on cleaning and product care visit: https://www.happybeds.co.uk/help-and-advice Notes We’ve tried to make this product as easy to assemble as possible. In the unlikely event that...
