- Page 2 Vendor: S000107 Parts List Hardware List (found in box 1) Part Description Part Description Headboard foot 1/4" x 80 mm Bolt Headboard foot Elliptical Nut Headboard 7 x 100 mm Bolt Foot end 10 x 40 mm Wooden Dowel Allen Key Foot end Rail Spacer Block 96 mm...
- Page 3 Vendor: S000107 Step 1:Insert the wooden dowels (D) into the headboard (3), then set up the legs (1) and (2) in the headboard (3) setting the parts with the bolts (C) with the allen key (E). Step 2: Insert the wooden dowels (D) into the rail (6), then set up the legs (4) and (5) in the rail (6) setting the parts with the bolts (C) with the allen key (E).
- Page 4 Vendor: S000107 Step 3: Put the wooden dowels (D) in the side rails (7), then set up the footend and the headboard in the siderails (7)setting them with the bolt (A) and the Elliptical nut (B) with the allen key (E). Step 4: Put the slats (8) distancing each other with the Spacer block (F) attach the slats with the screws (G) using a Philips screwdriver ( Not provided).
- Page 5 Vendor: S000107 Purchase order number: B00000 Page 5 of 5...
-
Page 6: General Care And Maintenance
floor as this will cause damage to the joints and could result in failure to the product that will invalidate the warranty. For more information on cleaning and product care visit: https://www.happybeds.co.uk/help-and-advice Notes We’ve tried to make this product as easy to assemble as possible. In the unlikely event that...
