gCreate gMax 2 PRO Quick Start Manual page 2
Hide thumbs
Also See for gMax 2 PRO:
- User manual (21 pages) ,
- Unboxing and setup instructions (9 pages)
Advertisement
gMax 2 PRO
Diagram
Lead Screw
Pillow Block
RGB LED
Light Bar
Lead Screw
Coupler
Electronics Box
USB Connection
SD Card Slot
LCD Screen
Power Button
Extruder
BLTouch
Bed Sensor
Extruder Drag Chain
Extruder Swing Arm
Extruder Drive Gear
Blower Fan
Hotend
Hotend Fan
(Active cooling)
Hotend
Nozzle
Filament Bracket
Extruder Carriage
Lead Screw Nut Block
X-Axis Arm
Lead Screw
Print Bed
(Acrylic or G10 FR4)
Bed Clips
Corner Foot Leveling
Power Supply
