SW-5004DE
HDMI 4x1 Seamless Switcher with Quad-view support
rev: 200713
Made in Taiwan
-1-

TABLE OF CONTENTS

INTRODUCTION .................................................................................................................... 2
FEATURES ............................................................................................................................ 2
PACKAGE CONTENTS .......................................................................................................... 2
SPECIFICATIONS .................................................................................................................. 3
PANEL DESCRIPTIONS ........................................................................................................ 4
CONNECTION DIAGRAM ...................................................................................................... 5
OPERATION APPROACH ...................................................................................................... 6
WARRANTY ......................................................................................................................... 11
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW-5004DE and is the answer not in the manual?

Questions and answers

Related Manuals for GoMax Electronics SW-5004DE

Summary of Contents for GoMax Electronics SW-5004DE

  • Page 1 TABLE OF CONTENTS SW-5004DE INTRODUCTION ........................2 FEATURES ..........................2 PACKAGE CONTENTS ......................2 SPECIFICATIONS ........................3 HDMI 4x1 Seamless Switcher with Quad-view support PANEL DESCRIPTIONS ......................4 CONNECTION DIAGRAM ...................... 5 OPERATION APPROACH ...................... 6 User Manual WARRANTY ......................... 11...
  • Page 2 INTRODUCTION SPECIFICATIONS The SW-5004DE HDMI 4x1 Seamless Switcher with Quad-view support provides the most flexible and Model Name SW-5004DE cost effective solution in the market to route high definition video source from one of the four HDMI Technical sources to the remote display in real time. This solution can be utilized in digital signage, conference...
  • Page 3 PANEL DESCRIPTIONS CONNECTION DIAGRAM 1. Input Selection Button: Input 1~4 source selection (from the left to the right is input 1, input 2, input 3, and input 4). If you press the input 1 button about 5 seconds, the output layout will change to Quad-view mode ( 2.
  • Page 4 OPERATION APPROACH Method A: IR Remote Control Button Function POWER Power on/off the device INFO Display input/output/audio information of device MUTE Turn off output’s video and audio Fade Fade switching effect Dissolve Dissolve switching effect Seamless Seamless switching effect Audio Select audio channel Quad Change the output layout to...
  • Page 5  (2) System Firmware Version Get the firmware version information.  Firmware Update Firmware update device  Please select the correct COM port or click “Scan” button to connect device.  MAC Address Display the device’s MAC address information  Network Setting User can use the Ethernet to control the switcher.
  • Page 6 WARRANTY button to change it. The SELLER warrants the SW-5004DE HDMI 4x1 Seamless Switcher with Quad-view support free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period,...
