- Page 1 8x8 3G/HD/SD-SDI Matrix User Manual rev: 160801 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the MA-3188 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
The matrix master can switch every output channels to any SDI inputs by push-in button, IR remote controller or RS-232 control Easy installation with rack-mounting and wall-mounting designs for master and receiver respectively PACKAGE CONTENTS 1x MA-3188 1x Rack-mounting ear set 1x IR Remote control 1x User Manual ... -
Page 4: Specifications
SPECIFICATIONS Model Name MA-3188 Technical Role of usage True 8x8 matrix Video bandwidth 2.97 & 2.97/1.001Gbps [3G] 1080p@50/59.94/60 (4:2:2) Video support [HD] 720p50/59.94/60, 1080p24/30, 1035i50/59.94/60, 1080i50/59.94/60 [SD] NTSC@59.94Hz, PAL@50Hz Audio support [3G] up to 100m(300ft) / [HD-SDI] up to 150m (500ft) / [SD-SDI] up to 300m... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Front Panel 1. Power Switch: Power ON/OFF switch 2. IR Sensor: IR sensor for receiving the IR commands from IR remote 3. Output Push Button & 7-segment LED: Front panel push buttons used to select the number of display channels &... -
Page 6: Connection Diagram
HARDWARE INSTALLATION MA-3188 1. Connect all sources to SDI Inputs on the 8x8 SDI matrix 2. Connect all outputs to SDI Receiver 3. Connect the AC power supply to the 8x8 SDI matrix 4. Power on the 8x8 SDI matrix MA-3188... -
Page 7: Operation Approach
OPERATION APPROACH Method A: Push-in Button IN/OUT MAP 1) Use the “+”or “-“ output push button to select the number of display 2) Use the “+”or “-“ input push button to select the number of input source “+”: change selected input/output port in ascending order “-”... - Page 8 Method C: Software Control through RS-232 port System Requirements and Precautions 1. Whenever power off MA-3188, please stay unpowered at least 5 to 10 seconds to allow power capacitors to discharge. 2. The MA-3188 provides software control program under Microsoft Windows XP, 7, 8 through the interface of RS-232 control port 3.
- Page 9 3. Connection Status Show the connect status (Connected or Disconnected). 4. In/Out switch panel For each output, you can assign arbitrary video source or mute output video here. 5. Firmware Update The “Firmware update” window shows up as below. Before firmware update process, please ensure your RS-232 cable is connecting and the status is “CONNECTED”.
- Page 10 7. Default Reset To do factory default reset. This default reset process will take about 10 seconds. Method D: Terminal control: Baud rate: 115200 Data length: 8bit Parity check: No Stop bit: 1 COMMAND ACTION ST + 0x0d Show all mapping PON + 0x0d Power on the device POFF + 0x0d...
-
Page 11: Limited Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the MA-3188 v1.2/v1.3 features and specifications is subject to change without further notice...
