- Page 1 4x1 HDMI Switch with IR User Manual rev: 130628 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the SW-5004R should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
The SW-5004R has 4 input HDMI definition receptacle connectors and 1 output HDMI definition receptacle connector. Users simply connect all the HDMI/DVI sources to the inputs of SW-5004R, and then connect HDMI/DVI equipped display system on the output port. Via IR remote control or front panel button, users can select which source they would like to be displayed. -
Page 4: Specifications
SPECIFICATIONS Model Name SW-5004R Technical Role of usage 4x1 switch HDMI compliance HDMI Deep Color HDCP compliance Video bandwidth 6.75 Gbps Video support 480p, 720p, 1080i, 1080p, and VESA resolutions Transmission up to 15m/50ft at 1080p Surround sound (up to 7.1ch) or stereo digital audio... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Front Panel Rear Panel IR Sensor Serial channel control HDMI OUT channel push button and indicator LED HDMI Input 1~4 IR Receiver +5V DC... -
Page 6: Hardware Installation
2. Connect your HDMI/DVI sources to the input ports of SW-5004R. 3. Connect your HDMI/DVI enabled receiver (monitors etc.) into the output port of SW-5004R. 4. Power up SW-5004R. 5. Select the input you want to be displayed on the connected monitor with IR remote control or push button on the front panel. -
Page 7: Ir Remote Control
IR REMOTE CONTROL Function Key Function Description POWER Reserved Reserved Reserved SOURCE SELECT 1 Select HDMI INPUT 1 to be the input source SOURCE SELECT 2 Select HDMI INPUT 2 to be the input source SOURCE SELECT 3 Select HDMI INPUT 3 to be the input source SOURCE SELECT 4 Select HDMI INPUT 4 to be the input source HDMI PIN DEFINITION... -
Page 8: Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the SW-5004R features and specifications is subject to change without further notice.
