GoMax Electronics EX-57AL-2K Series User Manual

EX-57AL-2K
HDMI 2.0 over IP Light Compression Multicast
System
User Manual
TX RX
rev: 180420
Made in Taiwan
The EX-57AL-2K
HDMI 2.0 over IP Light Compression Multicast System
conformance to safety regulations and requirements, and has been certified for international
use. However, like all electronic equipments, the EX-57AL-2K should be used with care.
Please read and follow the safety instructions to protect yourself from possible injury and to
minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is
on a stable surface.
● Use only the power adapter and power cords and connection cables designed for this
unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the
device before cleaning.

TABLE OF CONTENTS

INTRODUCTION ................................................................................................................. 1
FEATURES ......................................................................................................................... 1
PACKAGE CONTENTS ...................................................................................................... 1
SPECIFICATIONS .............................................................................................................. 2
PANEL DESCRIPTIONS ..................................................................................................... 3
IR PASS-THROUGH ........................................................................................................... 5
HDMI PIN DEFINITION ....................................................................................................... 6
CONNECTION DIAGRAM ................................................................................................... 7
OPERATION APPROACH .................................................................................................. 8
WARRANTY ..................................................................................................................... 12
