Remove all contents from packaging and inspect to ensure no damage was incurred during shipping. Package should also

include the following:

always disconnect

Assemble spoke handle assembly (item #30) to pinion feed shaft (item #15) using screw which is attached to center of

drive handle. NOTE: Handle can be mounted on right or left side of machine.

what you should know before you drill

1. The Magforce™ incorporates state of the art design features such as "SMART MAGNET"™ circuitry. This feature

does not allow the motor to operate in unsafe magnetic holding conditions. Illuminated on/off switches indicate the

existence of a sufficient magnetic field. If On/Off switches are not illuminated, there is not a proper magnetic field.

When drilling materials under 3/8" thick, an additional steel plate may be required to achieve proper magnetic

adhesion.

2. Type of material to be drilled, Brinnell or Rockwell hardness, material thickness and position should all be

determined to ensure proper selection of Slugger® cutting tools, RPM, coolant and drilling time.

3. Remove any excessive mill scale or rust from surface to be drilled.

4. Material that has been flame cut may have become heat-treated and therefore difficult to drill. Avoid drilling

near such areas whenever possible.

5. Drilling with the Magforce™ in horizontal positions requires a special lubrication for Slugger® cutters.

Consult Jancy Engineering for details.

6. Do not use Slugger® drilling machines on surfaces or materials being welded.

Doing so can damage the machine's electrical components.
