machine and spoke handle parts list

item description
1 FRAME ASSEMBLY
2 BALL BEARING
3 FIELD, 120V
FIELD, 220V
4 ARMATURE ASSEMBLY, 120V
ARMATURE ASSEMBLY, 220V
5 M4 X 10 FHSCS
6 QUILL ASSEMBLY
7 HELICAL GEAR
8 EXTERNAL RETAINING RING
9 OUTPUT PINION ASSEMBLY
10 INTERMEDIATE PINION ASSEMBLY
11 M5 X 12 DOWEL PIN
12 GEARBOX COVER ASSEMBLY
13 M4 X 12 SHCS
14 M4 LOCK WASHER
15 PINION FEED SHAFT
16 EXTERNAL RETAINING RING
17 PCB BASE
18 PC BOARD, 120V
PC BOARD, 220V
19 PCB COVER
20 M4 X 20 SHCS
21 POWER CORD ASSEMBLY, 120V
POWER CORD ASSEMBLY-AS SPECIFIED, 220V
22 M3 X 5 CRPHMS
23 M3 LOCK WASHER
24 MAGNET ASSEMBLY, 120V
MAGNET ASSEMBLY, 220V
25 SAFETY STRAP LINK
26 SAFETY STRAP
27 M5 X 20 SHCS
28 M5 LOCK WASHER
29 COOLANT BOTTLE ASSEMBLY
30 SPOKE HANDLE ASSEMBLY
31 MOTOR BRUSH
32 BRUSH CAP
33 SPECIFY 2 OR 4 BUTTON AND VOLTAGE
34 #2 X 3/16" DRIVE SCREW
35 MAGNET SWITCH ASSEMBLY
36 GUARD ASSEMBLY
SPOKE HANDLE ASSEMBLY PARTS LIST
item description
1 HUB
2 SPOKE HANDLE
3 M6 X 30 SHCS (NOT SHOWN)
4 1/4" PUSH NUT (NOT SHOWN)
MACHINE PARTS LIST
#
part qty
06936V1 1
UH3045 1
06922A 1
06923A
06914 1
06915
UH0410 8
06908 1
06802 1
UH4016 1
06910 1
06912 1
UH4200 2
06944 1
UH0422 8
UH2044 8
06206 1
UH4050 1
06328 1
U55006 1
U55008
06330 1
UH0434 2
06935 1
UH0300 1
UH2035 1
06907 1
06905
U11004 1
U11005 1
UH0542 4
UH2054 4
06934 1
06315 1
04549 2
04552 2
CALL 1
UH1002 2
06511 1
06940 1
#
part qty
U12004 1
U12200 3
UH0654 1
UH4600 1
