connection diagram

PC BOARD
(PN U55006)
R SW
MAGNET
MAGNET POWER CONNECTOR
MAGNET REED SWITCH CONNECTOR

machine frame breakdown and parts list

BLACK
WHITE
MTR SW
POWER
item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
PUSH-BUTTON
HARNESS
(PN 06962V1)
MOTOR OFF
PUSH BUTTON
(RED)
RED
RED
MOTOR ON
PUSH BUTTON
(GREEN)
BLACK
WHITE
NOT
USED
3
2
1
ON
OFF
6
5
4
MAGNET
ON / OFF
SWITCH
(PN 06510)
BLACK
BLACK
WHITE
POWER SUPPLY CORD
GREEN
description
MACHINED FRAME
1/4" X 3/8" DOWEL PIN
FLANGE BEARING
FLANGE BEARING
MOTOR BRUSH HOLDER
M5 X 5 CPSSS
PUSH BUTTON SWITCH ASSY.
OVERLAY
LOUVER ASSEMBLY
M4 X 12 SHCS
M4 LOCK WASHER
M10 X 10 NTSSS
PLUG PLATE
INNER SLEEVE BUSHING
MOTOR
M
BLACK
#
part qty
06302J 1
UH4318 1
UH3320 1
UH3310 1
04551 2
UH0500 2
06962V1 1
06410 1
06939 1
UH0422 2
UH2044 2
UH0902 1
06106V1 1
06719 1
11
