for Living 168-0102-0 Assembly Instructions Manual
  1. Manuals
  2. Brands
  3. for Living Manuals
  4. Indoor Furnishing
  5. 168-0102-0
  6. Assembly instructions manual

for Living 168-0102-0 Assembly Instructions Manual

Office chair with head rest
Hide thumbs

Advertisement

Quick Links

Download this manual
Office Chair with Head Rest
Product No. 168-0102-0
Assembly Instructions
NEED HELP? GIVE US A CALL!
WE'RE HERE FOR YOU.
TOLL-FREE:
1-877-483-6759
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 168-0102-0 and is the answer not in the manual?

Questions and answers

Related Manuals for for Living 168-0102-0

Summary of Contents for for Living 168-0102-0

  • Page 1 Office Chair with Head Rest Product No. 168-0102-0 Assembly Instructions NEED HELP? GIVE US A CALL! WE’RE HERE FOR YOU. TOLL-FREE: 1-877-483-6759 IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference.
  • Page 2 From your first apartment to downsizing your family home, ® LIVING is a great place to start. Uncomplicate your life with timeless style and reliable quality that delivers everyday solutions for your home. Let us know how our products work for you. Rate and review at canadiantire.ca...

  • Page 3: Table Of Contents

    Table of Contents Technical Data Parts List Hardware List Troubleshooting Before You Begin Assembly Caring for Your Item Step-by-step Guide Warranty Warning! Please use your furniture correctly and safely. Improper use can cause safety hazards or damage to your furniture or household items.

  • Page 4: Parts List

    Parts List Item Description Thumbnail Quantity Backrest Seat Seat Plate Cylinder Base Castor Cylinder Cover Office Chair with Head Rest...
  • Page 5 Exploded Parts 7 x 5 Office Chair with Head Rest...

  • Page 6: Hardware List

    Hardware List Item Description Thumbnail Quantity M6x20 Combination Bolt M6x25 Combination Bolt M6x35 Combination Bolt Hex Key Office Chair with Head Rest...

  • Page 7: Before You Begin Assembly

    Place packing materials back in the box. Do not dispose of packaging materials until assembly is complete. Read Each Step Carefully Make sure you understand each step. If you have any questions, Call the for LIVING ® customer service centre at 1-888-660-6684 (toll free).

  • Page 8: Step-By-Step Guide

    Step-by-step Guide Step 1 Insert five castors (7) into the base (6). Push hard until you feel or hear the castors (7) snap into place. Office Chair with Head Rest...
  • Page 9 Step-by-step Guide Step 2 Remove cap from cylinder (5). Office Chair with Head Rest...
  • Page 10 Step-by-step Guide Step 3 Attach cylinder (5) into base (6) as shown. Place cylinder cover (8) over cylinder. Office Chair with Head Rest...
  • Page 11 Step-by-step Guide Step 4 Attach seat plate (4) to seat (2) with tension knob facing the front of the seat. Secure using four bolts (A) and he key (E). Office Chair with Head Rest...
  • Page 12 Step-by-step Guide Step 5 Attach arms (3) to seat (2). Secure using four bolts (C) and he key (E). Note: Do not tighten screws all the way until you’ve assembled the chair. Once assembly is complete, tighten each screw. Office Chair with Head Rest...
  • Page 13 Step-by-step Guide Step 6 Attach backrest (1) to arms (3) using four bolts (B) and he key (E). Note: Do not tighten screws all the way until you’ve assembled the chair. Once assembly is complete, tighten each screw. Office Chair with Head Rest...
  • Page 14 Step-by-step Guide Step Tighten all the screws. Cover the screws attaching the backrest (1) to arms (3) using four caps (D). Office Chair with Head Rest...

  • Page 15: Technical Data

    Technical Data 46 1/2 – 50 1/4 " (11 .5 – 12 cm) 26 3/4" (6 cm) 26 3/4" (6 cm) Specifications Assembled Dimensions (W x D x H) 26 3/4 x 26 3/4 x 46 1/2 50 1/4'' 68 x 68 x 118.5 128 cm Assembled Weight 29 lb 12 oz 13.5 kg...

  • Page 16: Troubleshooting

    Troubleshooting Need help? 1-877-483-6759 Give us a call! We’re here for you. Toll-free: Before returning your Call us first! If you have questions regarding your product product to store or require warranty assistance, please call our customer service helpline. Caring for Your Item Always keep children under close supervision while they are using or around this product.

  • Page 17: Warranty

    Warranty 1-Year Limited Warranty* ® This For LIVING product carries a one (1) year warranty against defects in workmanship and materials. Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase.
