for Living 088-1648-6 Assembly Instructions

ATTENTION:THIS PRODUCT IS NOT FOR COMMERCIAL
!

PARTS LIST

PART
MATERIAL CODE
NO.
1
TCS64LC-CS05-1
2
TCS64LC-CS04-1
3
13C??1B29008001
Note:
The tiles can be easily broken, be careful when you
remove them. Do not throw the residual tiles away.
Retain them for future use.

Step 1:

Place the table top (1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the legs (2) to the underside of the table top (1)
rim by using bolts (4) and washers (5). Make sure that
all of the bolts have been tightened completely and
cover them with bolt caps (6).
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely assembled.
!
Do not sit or stand on this table.
!
! A weighted umbrella base must be used when using an umbrella with this table.
! Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
required.
! Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Sutton Collection Dining Table
088-1648-6 (TCS64LC)
ASSEMBLY INSTRUCTIONS
USE INTENDED FOR RESIDENTIAL USE ONLY.
