Orion
Tritech II-M Stabilized Monopod with 3-Way Pan Head
®
3-way pan head
Bubble
level
Foam grip
Flip lever leg
locks
Figure 1.
Key features (Shown with retractable mini tripod stand
deployed.)
CAUTION: While the mini tripod stand can help stabilize
the monopod while in use, it is not designed to support an
unattended camera or spotting scope. Always maintain a
firm grip on your camera or spotting scope with one hand
– even when the mini tripod stand is deployed – to prevent
the monopod from tipping over.
A N E M P L O Y E E - O W N E D C O M P A N Y
Copyright © 2022 Orion Telescopes & Binoculars. All Rights Reserved. No part of this product instruction or any of its contents
may be reproduced, copied, modified or adapted, without the prior written consent of Orion Telescopes & Binoculars.
INSTRUCTION MANUAL
#40810
Quick-release plate
Handle angle
adjustment
Handle
Hand strap
Mini tripod stand
A
Adjustable
handle
collar
Handle
Handle
angle
adjustment
A
knob
C
Figure 3.
Attach the handle to the pan head with the handle
(A)
adjustment knob
. To change the handle angle, just loosen the handle
adjustment knob until the handle can be rotated, then retighten the knob
when the desired angle has been set.
you rotate and lock the 3-way pan head's azimuth (horizontal), altitude
(C)
(vertical), and lateral tilt
.
Corporate Offices: 89 Hangar Way, Watsonville CA 95076 - USA
Toll Free USA & Canada: (800) 447-1001
International: +1(831) 763-7000
Customer Support: support@telescope.com
B
Figure 2. Fold the mini tripod legs
down (A) until they click into the
locked position. To fold them back
up, (B) press the two spring pegs
inward, then lift the leg up.
Lateral tilt
adjustment
knob
Altitude
adjustment
knob
Azimuth
adjustment
knob
B
(B)
Three adjustment knobs let
IN 574 08/16
