INSTRUCTION MANUAL
Orion
Camera Roof Mount
Parts List
• Roof mount bracket
• Adapter plate
• 4x short Hexagonal head
screws
• Hexagonal Allen Key
• 3x Philips head screws
• 3x Wall plugs
• 3x Nuts
• 3x Bolts
Providing Exceptional Consumer Optical Products Since 1975
Starshoot
®
#5862
OrionTelescopes.com
Customer Support (800) 676-1343
E-mail: support@telescope.com
Corporate Offices (831) 763-7000
89 Hangar Way, Watsonville, CA 95076
© 2011 Orion Telescopes & Binoculars
AllSky
™
Required tools (Not supplied)
• Tamper proof Allen key
(supplied with Starshoot AllSky
Camera)
• Small Philips head screwdriver
• Dowel or small screwdriver (for
making holes)
• Tube of outdoor waterproof
silicon sealant
IN 428 Rev. A 10/11
