ORION TELESCOPES & BINOCULARS Tritech II-M Instruction Manual

Orion Tritech II-M Stabilized Monopod with 3-Way Pan Head
®
3-way pan head
Bubble
level
Foam grip
Flip lever leg
locks
Key features (Shown with retractable mini tripod
Figure 1.
stand deployed.)
CAUTION: While the mini tripod stand can help stabilize the monopod
while in use, it is not designed to support an unattended camera
or spotting scope. Always maintain a firm grip on your camera or
spotting scope with one hand – even when the mini tripod stand is
deployed – to prevent the monopod from tipping over.
INSTRUCTION MANUAL
Quick-release plate
Handle angle
adjustment
Handle
Hand strap
Mini tripod stand
#40810
A
Fold the mini tripod legs down (A) until they click
Figure 2.
into the locked position. To fold them back up, (B) press
the two spring pegs inward, then lift the leg up.
Handle
A
C
Attach the handle to the pan head with the
Figure 3.
handle adjustment knob
just loosen the handle adjustment knob until the handle
can be rotated, then retighten the knob when the desired
angle has been set.
rotate and lock the 3-way pan head's azimuth (horizontal),
altitude (vertical), and lateral tilt
B
Lateral tilt
adjustment
knob
Adjustable
Altitude
handle
adjustment
collar
knob
Azimuth
adjustment
knob
Handle
angle
adjustment
B
knob
. To change the handle angle,
(A)
Three adjustment knobs let you
(B)
.
(C)
