922Z POWERC@M OPTICAL ZOOM
U K
User's manual
P T
T R U S T . C O M
L I F E I S M O R E ! T R U S T U S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWERCAM 922Z and is the answer not in the manual?

Questions and answers

Related Manuals for Trust POWERCAM 922Z

Summary of Contents for Trust POWERCAM 922Z

  • Page 1 922Z POWERC@M OPTICAL ZOOM User’s manual T R U S T . C O M L I F E I S M O R E ! T R U S T U S...
  • Page 2 Thank you for your purchase. Register your product via our Internet site at www.trust.com/register, so that you will be eligible for optimal guarantee and service support. You will also be automatically informed of the development of your and other Trust products. T R U S T . C O M...
  • Page 3 922Z POWERC@M OPTICAL ZOOM Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 9 T R U S T . C O M L I F E I S M O R E ! T R U S T U S...
  • Page 4 TRUST 922Z POWERC@M OPTICAL ZOOM Introduction This instruction manual is for users of the TRUST 922Z POWERC@M OPTICAL ZOOM. This product can be used for (1) making still photo; (2) making macro photo; (3) making video clip. The built-in memory storage of this camera is 16MB and can be easily expanded by using a SD (Secure Disk) or MMC (Multi-Media Card) card.
  • Page 5 TRUST 922Z POWERC@M OPTICAL ZOOM Approval This device meets the essential requirements and other relevant conditions of the applicable European directives. The Declaration of Conformity (DoC) is available at www.trust.com/13788/ce. Parts and Explanation Refer on Fig. 1, Item Description Function...
  • Page 6 TRUST 922Z POWERC@M OPTICAL ZOOM Item Description Function is in Capture mode or Playback mode. DC-in & USB connector DC-in, for purchased optional adapter (5V, 2A). This only supplies power, no battery charge function. USB, for making connection to a PC with supplied USB cable.

  • Page 7: Install Battery

    TRUST 922Z POWERC@M OPTICAL ZOOM Description Function Protect image In playback mode, to protect images/videos from being deleted (shift OK button top). Self timer To take photograph automatically by self- timer (shift OK button right once!). Continuous shot To take continuous photographs by pushing shutter button once (shift OK button right twice!).
  • Page 8 TRUST 922Z POWERC@M OPTICAL ZOOM Battery full. Battery half full. Battery almost empty. Battery empty. Recharge the battery. Table 1: Battery status on the LCD screen Note: The battery should be removed if the camera is not going to be used for some time.

  • Page 9: Flash Setting

    TRUST 922Z POWERC@M OPTICAL ZOOM Note: 4 x digital zoom are all supported in playback mode! Note: You are able to see the zoom effect in viewfinder only when using optical zoom! 6.3 Flash setting 1. Set the camera in either capture or macro mode.

  • Page 10: Connecting Camera To Computer

    In the example, ‘D:\’ is used to indicate the CD-ROM drive. This may be different for your computer. Note: Use the language alter box on the top-right corner of Trust installer to select the language you want to use for installation. Insert the CD-ROM into your computer’s CD-ROM drive. The installation program will start automatically.

  • Page 11: Check After Installation

    TRUST 922Z POWERC@M OPTICAL ZOOM 10.1 Check after installation After installing the driver and connect the camera, the following are installed on your computer and can be checked. Taskbar - An icon ‘ ’ will be visible in the right of your taskbar.
  • Page 12 TRUST 922Z POWERC@M OPTICAL ZOOM In this mode, you will be able to adjust the settings of the camera. Refer on the table of description below and use the 5-way OK button to select the option you want and push down the OK button to make a selection.
  • Page 13 TRUST 922Z POWERC@M OPTICAL ZOOM Note: When there’s nest menu, select the option you want first by pushing down the OK button and the further options will show up. And always use the 5-way OK button to select an option you want.
  • Page 14 TRUST 922Z POWERC@M OPTICAL ZOOM The default setting is ‘Off’ but it can be activated by shifting the OK button right once. The symbol for the automatic exposure function will appear in the middle of the LCD screen. Press the shutter button (2, figure 3) to take a photograph using the automatic exposure function.
  • Page 15 TRUST 922Z POWERC@M OPTICAL ZOOM lighting. Fluorescent- - Fluorescent fluorescent lighting. - Normal [Default] Enhance the edge detail of Sharpness the photograph. - High - Low Value from +2.0 ~ -2.0. Exposure Value, which allows EV Adjust Steps in 0.5. Default value users to control the exposure is 0.
  • Page 16 TRUST 922Z POWERC@M OPTICAL ZOOM First, turn the mode dial to ( ). In this mode, the usage, menu settings are all the same as in capture mode but it’s mainly used to take close-up still photographs, distance of 15 to 50 cm: from camera lens to object taken.
  • Page 17 There are a number of conditions attached to the use of this site. The conditions can be found at www.trustphotosite.com. This software can be used to upload your photographs to the Trust Photo Site. Note: The latest version of the Trust Photo Upload software can always be downloaded from the Trust website.
  • Page 18 TRUST 922Z POWERC@M OPTICAL ZOOM Follow the on-screen instructions to complete the installation. 13.2. Using Trust photo site You must first register with Trust before you can upload photographs to the Trust Photo Site. 13.2.1 Register first Go to Trust website (www.trust.com) to register yourself and your camera.

  • Page 19: Troubleshooting

    Select 'Run' from the Windows Start menu. Select 'Run' from the Windows Start menu. Type [D:\SETUP.EXE] and click on 'OK' to start the Trust Software Type [D:\SETUP.EXE] and click on 'OK' to start the Trust Software Installer. Installer.
  • Page 20 TRUST 922Z POWERC@M OPTICAL ZOOM The camera is set to the Reduce the resolution to 3.1 The digital zoom does not work. 5.5 Megapixel resolution. Megapixels or less. The camera is turned off. Turn the camera on (see The camera does not quick install).
  • Page 21 TRUST 922Z POWERC@M OPTICAL ZOOM not sharp. correctly for the distance position. to the object. In the case of noise, select a The recordings contain a Fewer photographs location with more light. lot of detail or noise. can be taken than If there is too much detail, it expected.
  • Page 22 TRUST 922Z POWERC@M OPTICAL ZOOM Windows does not The computer's USB port Check the settings of your does not work. USB port. For more detect a new device information, see after connecting the www.trust.com/customercar camera. e/help/usb. The camera has not been Connect the camera to a connected to a USB port.

  • Page 23: Technical Specifications

    Or check Windows Help Or search topics on internet If you still have problems after trying these solutions, please contact one of the Trust Customer Care Centers. You can find more information at the back of this instruction manual. Please have the following information available: •...

  • Page 24: Warranty Conditions

    TRUST 922Z POWERC@M OPTICAL ZOOM LCD screen 1.6” colour TFT LCD, 80000 pixel and higher Digital zoom 4x (for photographs) Exposure -2.0 -> 0 -> +2.0 White balance Auto / Sun / Shade / Fluorescent / Tungsten Lens 3x Optical zoom lens, F=2.8 ~ 4.8, 5.8 ~ 17.4mm...

  • Page 25: Customer Care Centers

    CUSTOMER CARE CENTERS 24 HOURS free service: www.trust.com Residents in the UK and Ireland should contact: UK Office Mon - Fri Phone +44-(0)845-6090036 From 8:00 - 16:00 +31-(0)78-6543299 I residenti in Italia possono contattare: lun - ven Ufficio italiano 9:00 - 13:00 /...
