Trust POWERCAM CCD 960 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
960 POWERC@M CCD
U K
User's manual
D E
F R
I T
E S
P L
N L
P T
V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWERCAM CCD 960 and is the answer not in the manual?

Questions and answers

Related Manuals for Trust POWERCAM CCD 960

Summary of Contents for Trust POWERCAM CCD 960

  • Page 1 960 POWERC@M CCD User’s manual V1.1...
  • Page 2 Thank you for your purchase. Register your product via our Internet site at www.trust.com/register, so that you will be eligible for optimal guarantee and service support. You will also be automatically informed of the development of your and other Trust products.
  • Page 3 960 POWERC@M CCD Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5...
  • Page 4 960 POWERC@M CCD Fig. 6 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11...

  • Page 5: General Comments Regarding Photography

    (20) Introduction This instruction manual is for users of the TRUST 960 POWERC@M CCD. This This instruction manual is for users of the TRUST 960 POWERC@M CCD. This camera has a CCD lens to guarantee sharp images. The camera has a maximum camera has a CCD lens to guarantee sharp images.
  • Page 6 Safety Carefully read the following instructions before use. The TRUST 960 POWERC@M CCD does not require any special maintenance. Use a slightly damp, soft cloth to clean the camera. Do not use aggressive substances, such as white spirit, to clean the device.

  • Page 7: Inserting/Removing The Batteries

    TRUST 960 POWERC@M CCD Inserting/removing the batteries Follow the instructions given below to insert or remove the batteries. Note: Make sure the camera is turned off. Open the battery cover (1, figure 3) on the bottom of the camera by sliding it in the direction indicated by the arrow and folding it open.

  • Page 8: Explanation Of The Camera Functions

    TRUST 960 POWERC@M CCD Explanation of the camera functions Functions on the top of the camera (see figure 1). Point Description Function Exposure button Press this button to take a photograph. This button is also used to start and stop recording a video clip.
  • Page 9 TRUST 960 POWERC@M CCD Functions on the bottom of the camera (see figure 3). Point Description Function Battery and memory card Protects the batteries and the cover memory card. Screw point for stand The stand supplied or a different stand can be screwed in here.
  • Page 10 TRUST 960 POWERC@M CCD Symbols on the LCD screen (see figure 5). Point Description Function Mode indicator Indicator when taking photographs or recording video clips. The video indicator is also displayed in the display mode. Sound recording Indicator for recording sound.

  • Page 11: Standard Camera Operation

    TRUST 960 POWERC@M CCD STANDARD CAMERA OPERATION The following chapters explain how to take a photograph, how to view the photograph on the camera and how to save the photograph on a computer. Taking photographs Open the lens protector (9, figure 2) using the slide next to the lens (8, figure Slide the On/Off switch (2, figure 4) to the right and keep it in that position for 1 second.
  • Page 12 Select 'Run' from the Windows Start menu. b Type [D:\SETUP.EXE] and click on 'OK' to start the Trust Software Installer. The Trust Software Installer window will appear (see figure 8). Select the language (in the top right-hand corner) you wish to use for the installation.

  • Page 13: Symbol Function

    TRUST 960 POWERC@M CCD A window will appear automatically which gives you various options. Select ‘Using folder to view files’ (see figure 9). Double-click on the ‘DCIM’ folder. Double-click on the ‘100MEDIA’ folder. This folder contains all the recordings saved on the camera.

  • Page 14: Attaching The Wrist Strap

    TRUST 960 POWERC@M CCD Stand The stand supplied with the camera can be used to keep the camera stable. It is recommended to use the stand when using the automatic exposure function or when using the macro setting. Screw the stand into place on the bottom of the camera (2, figure 3).

  • Page 15: Automatic Exposure

    TRUST 960 POWERC@M CCD 10.2 Using the macro function (close-up photographs) The Trust 960 PowerC@m CCD has a macro function which can be used to take photographs at a minimum distance of 20 cm. Selecting the macro mode: Slide the macro button (5, figure 2) upwards or downwards (see table 8 for an explanation).

  • Page 16: Setting The Flash

    TRUST 960 POWERC@M CCD 10.4 Setting the flash The camera has variou flash options. Selecting the flash: Set the camera to the ‘Capture’ mode. Press the control button downwards. Repeat this until the correct setting has been reached (see table 9).
  • Page 17 TRUST 960 POWERC@M CCD Symbol on the Point Options screen Comments 1280 x 960 = 1.3 Megapixel) 1280 x 960 (S) Compression Super Fine Sets the compression ratio (see chapter 10.5.2). (Quality) Fine Normal Audio Records sound after a photograph recording has been saved.

  • Page 18: White Balance

    TRUST 960 POWERC@M CCD (XL) Quality Super Fine Fine Normal Table 11: Number of photographs that can be saved in the camera’s internal memory 10.5.3 Exposure You can adjust the exposure to underexpose or overexpose photographs. This will make darker objects lighter or objects which are brightly lit less bright.
  • Page 19 TRUST 960 POWERC@M CCD Note: ‘Low light!’ is displayed on the LCD screen when there is insufficient light. Improve the lighting conditions or record a video clip in a different location. Increasing or reducing the distance to the object may also solve the problem.

  • Page 20: Menu Settings

    TRUST 960 POWERC@M CCD 12.2 Menu settings The following settings can be altered in the menu when the camera is in the ‘Playback’ mode: Delete, Slide show and Protect. Set the camera to the ‘Playback’ mode. Press the ‘Menu’ button.

  • Page 21: Slide Show

    TRUST 960 POWERC@M CCD Select ‘Yes’ to format the memory. Select ‘No’ to cancel the formatting. Note: All the photographs and video clips will be deleted when the memory is formatted, included the photographs and video clips protected against being deleted.

  • Page 22: Options Description

    Table 13: Settings Inserting/removing a memory card The Trust 960 PowerC@m CCD has a 16 MB internal memory. By default, photographs and video clips are saved in the internal memory. This memory can be increased by using a SD (Secure Digital) memory card. The photographs and video clips are automatically saved on the memory card when one has been inserted into the camera.

  • Page 23: Formatting The Memory

    TRUST 960 POWERC@M CCD Remove the memory card by pushing it so that the lock is released. Remove the memory card from the camera Close the battery cover. Note: The memory card can only be inserted into the camera in one way. Do not force the card into the slot.

  • Page 24: Software (Installation And Use)

    The conditions can be found at www.trustphotosite.com. 15.1 Installing the Trust Photo Upload software This software can be used to upload your photographs to the Trust Photo Site. Note: The latest version of the Trust Photo Upload software can always be downloaded from the Trust website.

  • Page 25: Installation

    Click on ‘Upload’. Enter your e-mail address and the password for your Trust registration (not the password for your e-mail account). Click on ‘Next’. Your login information will be checked. This may take some time.

  • Page 26: Using Ulead Cool 360

    Ulead’s Mira’ window may also appear. Click on the 'Skip for now' button to close these windows if they appear. The Trust camera will be visible as a ‘Removable disk’ in the list on the left- hand side of the window. (Click on My Computer.) Open the ‘100MEDIA’...

  • Page 27: Other Programs

    If you have not already installed the program on your computer, you can install it now. Follow the instructions given below to do this. Start the Trust Software Installer. Select ‘Install software’. Select ‘QuickTime 5.0’. Follow the on-screen instructions. You do not need to register this program.
  • Page 28 Ulead Photo Explorer 2.01 19.2.1 Installation Insert the CD-ROM into your CD-ROM drive. A Trust window will appear Click on ‘OK’. The installation window will appear. Click on ‘Install’. The files will now be copied to your hard drive. This may take some time.

  • Page 29: Troubleshooting

    Hard disk controllers – Trust 960 PowerC@m CCD (Win 98) Hard disk controllers – USB Mass Storage Device (Win 98) Disk drives – Trust 960 PowerC@m CCD USB Device (Win 2000, XP) Storage volumes – Generic Volume (Win 2000, XP) Universal Serial Bus controllers –...
  • Page 30 TRUST 960 POWERC@M CCD installed or locations other than the default locations have been selected). Note: Deviations may also occur as a result of using new drivers available on the Internet. Note: The location or name may vary in the Control Panel for different operating systems.
  • Page 31 TRUST 960 POWERC@M CCD Problem Cause Possible solution The camera was Try to hold the camera still or use The recordings are moved when taking a the stand. not clear (hazy). picture. The distance to the Increase the distance or use the subject is too small.
  • Page 32 Troubleshooter. If you still have problems after trying these solutions, please contact one of the Trust Customer Care Centers. You can find more information at the back of this instruction manual. Please have the following information available: •...

  • Page 33: Warranty Conditions

    TRUST 960 POWERC@M CCD Warranty conditions - Our products have a two-year manufacturer's warranty which is effective from the date of purchase. - If there is a fault, return the product to your dealer. Include an explanation of the fault, the proof of purchase and all the accessories.

  • Page 34: Service Centre

    SERVICE CENTRE 24 HOURS free service: www.trust.com Residents in the UK and Ireland should contact: UK Office Mon - Fri Phone +44-(0)845-6090036 From 8:00 - 16:00 +31-(0)78-6543299 I residenti in Italia possono contattare: lun - ven Ufficio italiano 9:00 – 17:00...
