DC-3500 POWERCAM MINI
PRODUCT INFORMATION
Front
1. Self timer LED
1. 'Mode' button
2. Flash
2. 'Key function' button
3. Lens
3. Tripod socket
4. Strap eyelet
4. TFT LCD monitor
Side
1. USB connection
2. Lens cover - focus switch
3. Battery cover
4. Memory card slot
5. Battery chamber
INSERT BATTERIES
1
2
Back
Top
1. 'Shutter' button
2. 'Power' button
3. Microphone
Key function buttons
1. Self-timer
/ Up
2. Zoom in
/ Right
/ Play-Pause
3. OK
4. Flash
/ Down
5. Zoom out
/ Left
1.
Open battery cover.
2.
Insert batteries (polarity indicated at battery
cover)
3.
Close battery cover.
Recommended: use rechargeable Ni-MH
batteries (www.trust.com/battery-chargers)
Do not mix different types or old and new
batteries.
1
UK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerCam Mini DC-3500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trust PowerCam Mini DC-3500

Summary of Contents for Trust PowerCam Mini DC-3500

  • Page 1 / Down 5. Battery chamber 5. Zoom out / Left INSERT BATTERIES Open battery cover. Insert batteries (polarity indicated at battery cover) Close battery cover. Recommended: use rechargeable Ni-MH batteries (www.trust.com/battery-chargers) Do not mix different types or old and new batteries.
  • Page 2 DC-3500 POWERCAM MINI TAKING PICTURES / RECORDING VIDEOS Slide down lens cover / focus switch Set focus: Macro 20 cm Normal 130 cm - ∞ Turn on camera. Change mode: Press ‘Mode’. See icon left top corner in LCD PICTURE: Set Still Image Mode (default).

  • Page 3: Connect To Computer

    Press ‘OK‘ • Select “YES” to delete; press ‘OK‘ CONNECT TO COMPUTER Turn on computer. Start Windows. Connect USB-cable to computer. Windows 98: install driver first, before connect. • Insert Trust Installation CD-ROM, • click “install driver” • follow instructions...
  • Page 4 DC-3500 POWERCAM MINI Connect USB-cable to camera. Turn on camera. Drivers installed automatically. PLAYBACK ON COMPUTER Windows XP 1, 3 Windows 2000, ME, 98SE 2, 3...
  • Page 5 DC-3500 POWERCAM MINI Windows XP Open folder: DCIM / 100MEDIA Select “Open folder to view files” *.JPG: Picture files *.AVI: Video files Go to step 3. *.WAV: Audio files Windows 2000, ME, 98: *.JPG: Picture files Double click “My Computer” *.AVI: Video files Double click “Removable Disk”...

  • Page 6: Install Software

    DC-3500 POWERCAM MINI INSTALL SOFTWARE Trust Photo Upload Software Application to upload pictures to the Trust PhotoSite (www.trustphotosite.com) Install: refer manual CD-ROM Ulead Photo Explorer 8.0 Photo Explorer has tools for acquiring, viewing, organizing, adjusting and printing digital images. Install: refer manual CD-ROM...
  • Page 7 DC-3500 POWERCAM MINI Mode Setting Option(s) remarks Still Image Mode Size 2560 x 1920 (5M) 2048 x 1536 (3M) *) 1600 x 1200 (2M) 1280 x 960 (1M) Quality S.Fine (***) Fine (**) Normal (*) *) Effect B&W Converts image to black and white.
  • Page 8 DC-3500 POWERCAM MINI Mode Setting Option(s) remarks Effect B&W Converts image to black and white. Normal *) Sepia Converts image to Sepia style Voice Record Record audio message. Press Shutter: start/stop recording SETUP File Reset Reset: file numbers start with 0001 after format, delete all images or insert new memory card...

  • Page 9: Insert Memory Card

    DC-3500 POWERCAM MINI INSERT MEMORYCARD Turn off camera. Open battery cover. Insert memory card into card socket. Press till clicks. Close battery cover. Pictures stored on memory card automatically when inserted. Format for first time use. (SET, Format, Yes, Memory card fit one way only. Do not force . ICON DISPLAY Item Symbol...
  • Page 10 DC-3500 POWERCAM MINI Item Symbol Remarks Double Focus range Macro Use lens cover switch Exposure Change in Setup, White Balance Automatic Change in Setup, Daylight Cloudy Fluorescent Sunset Tungsten Custom Memory card Memory card inserted Quality Super Fine Change in Setup, Fine Normal Size...

  • Page 11: Error Message Table

    DC-3500 POWERCAM MINI ERROR MESSAGE TABLE Messages Causes Solutions CARD FULL Insufficient card memory capacity to Delete stored image(s) store image. Insert a new memory card. MEMORY FULL Insufficient internal memory capacity to Delete stored image(s) in memory. store image. Insert a new memory card.
  • Page 12 Warranty & copyright • This product has a two-year manufacturer's warranty which is effective from the date of purchase. For more information see www.trust.com/warranty • Reproduction of this manual or any part of it is prohibited without permission from Trust International B.V.
