Operating Instructions
Warning Information
Parts Breakdown
Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities contains chemicals known to
cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how
often you do this type of work. To reduce your exposure to
these chemicals: work in a well ventilated area, and work with
approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
SPECIFICATIONS
Working Torque . . . . . . . . . . . . . . 0-20 ft. lbs.
Max. Torque . . . . . . . . . . . . . . . . . . . 25 ft. lbs.
Max. Free Speed . . . . . . . . . . . . . . . . . 250 rpm
Recom. Air Pressure . . . . . . . . . . . . . . . 90 psig
Overall Length. . . . . . . . . . . . . . . . . . . . . . 4.9"
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 lb.
Air inlet . . . . . . . . . . . . . . . . . . . . . . . . 1/8" npt
CAT-1000MR
CAT1000MR_manual_032805.indd 1
CAT-1000MR
1
• MAXIMUM RPM OF 250
• MAX AIR PRESSURE: 90 PSIG,
6.2 BAR
• RPM OF THE ACCESSORY
MUST EXCEED TOOL RPM
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
WEAR HEARING
PROTECTION
AVOID
PROLONGED
EXPOSURE TO
VIBRATION
1/4" Dr. Air Ratchet
3/28/05
5/6/05 7:50:09 AM
