8. Resources

The resources represent the list of the hardware that your
TB LT2
The being an all-in-one RTU has a fixed hardware all built within one module:
OX

A Power Supply

A CPU


Communication ports


Groups of I/O

If the CPU needs to communicate in 'ModBus Master' to another device (CPU, or an external
ModBus device), the latter must be declared as a Remote I/O card (see chapter 15: 'ModBus
Transactions')

The Resources also contain 2 lists with System variables. Systems variables have pre-defined
function (see chapter 8.5 'System variables')

8.1. The CPU Card

When starting a new document, TWinSoft creates automatically the CPU card corresponding to the
selection in the wizard (see chapter 5.).
The communication ports of the CPU with their associated configuration and the I/O of the CPU are part
from the resources of the CPU:
The CPU card is divided in several groups:
 Group 0 : communication ports
 Group 1, 2, 3, ... : different groups of I/O corresponding to the model of
20.7. for more details about I/O).
8.2. Communication Ports
Version : 1.09
TB LT2
has to its disposal.
