semaphore TBOX LT2-530 Series User Manual page 181

Menu of TWinSoft:
Plug...: Click this button to create the Plug & Go directory repository.
The name is unique. It means if you want to create Plug & Go files for several RTU's,
you have to save each file in separate directories.
Once the Project is compressed, the window displays File Info (see example above)
Plug Info...: Click this button and select the parent directory of repository directory to display its Info
Extract sources...:
System variable
A digital system variable indicates the presence of micro SD card:
29 MmcToRTU
Version : 1.09
once a repository has been selected (see Plug Info... above), allows extracting its
content
-
MMC: indicates whether the program has been loaded from the SD card:
1 = the program of SD card is different from the one of the RTU and has
been loaded from SD card
0 = there is no SD card; the SD card is empty; the program of the SD card
is identical to the one of the RTU
