- Page 1 VCC-F40X34 Rev.900-676-32-00 English XGA Color Analog Camera VCC-F40X34 Product Specification & Operational Manual CIS Corporation ©2010 CIS Corporation. All rights reserved.
-
Page 2: Table Of Contents
9. Initial Settings ............................. 15 10. CCD Optical Axis Accuracy ........................16 11. Dimensions ............................17 12. Cases for Indemnity (Limited Warranty) ....................18 13. CCD Pixel Defect ..........................18 14. Product Support ..........................18 ©2010 CIS Corporation. All rights reserved. -
Page 3: Scope Of Application
AC leaks from the connected devices may cause damages or destroy the camera. Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply voltage may cause damages or malfunction of the camera. ©2010 CIS Corporation. All rights reserved. -
Page 4: Product Outline
At Full Frame Scan Mode, entire pixels can be read out within approx. 1/30s. VCC-F40X34 is an analog interfaced camera. As an optional component parts, 12pins connector for power supply, HR10-10R012SA (HIROSE), can be enclosed. Please ask for the details. ©2010 CIS Corporation. All rights reserved. -
Page 5: Specification
・Fixed Shutter Trigger Operation Trigger Mode ・Pulse Width Trigger Operation Shutter speed 1/30 (OFF), 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, variable range 1/10000s Shutter speed set by trigger pulse width: 1/4～1/10000s (per 1H) ©2010 CIS Corporation. All rights reserved. - Page 6 Shock ±Y, ±Z, 6 directions. (without package) Temperature Operation guaranteed: -5℃～+45℃ Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity Temperature -25℃ ～ +60℃ Storage environment RH 20～80% with no condensation Humidity ©2010 CIS Corporation. All rights reserved.
-
Page 7: Camera Output Signal Specification
VS output 1.0V (p-p), Sync. Negative, 75Ω unbalanced, DC connect White clip level: 840 ± 40 -30mVp-p (Excluding SYNC) Video signal Setup level: 25 ± 10 mVp-p (Excluding SYNC) SYNC level: 280 ± 30 mVp-p RGB DC level: 290 ± 100 mV ©2010 CIS Corporation. All rights reserved. -
Page 8: Ccd Spectral Response (Representative Value)
VCC-F40X34 Rev.900-676-32-00 4.3. CCD Spectral Response (Representative value) ※ Lens characteristics and illuminant characteristics are not considered. ©2010 CIS Corporation. All rights reserved. -
Page 9: Function Settings
Shutter Speed = (791.5-Data)×42.33μs Max Data = 317Ch = 791 0～255 Manual White Balance Covers variable range 2600 ～ 9000K. R-Gain Control 0～255 Manual White Balance Covers variable range 2600 ～ 9000K. B-Gain Control ©2010 CIS Corporation. All rights reserved. - Page 10 Pulse Width Trigger Mode is a trigger operation to set shutter value (exposure time) with trigger pulse width. Trigger pulse width should be within the range over 2H (1/10000s) to less than approx. 1/4s. Shutter can be controlled by 1H. ©2010 CIS Corporation. All rights reserved.
-
Page 11: External Connector Pin Assignment
Power In DC+12V HD In/Out VD In/Out WEN Out Trig In 9 pins D-SUB Connector Pin No. R OUT G OUT B OUT SYNC OUT 6 pins Circular Connector HR-10-7R-6PA Pin No. RS232C TxD RS232C RxD ©2010 CIS Corporation. All rights reserved. -
Page 12: Timing Chart
1024CLK 246CLK HD Signal Output 141CLK 1270CLK 7.2. Vertical Synchronous Timing Chart HD Signal Output VD Signal Output Video Signal Output G Signal (G ON SYNC Mode) WEN Signal Output Active Area 768H 792H ©2010 CIS Corporation. All rights reserved. -
Page 13: Fixed Trigger Shutter Operation (Sync Reset Type)
ADDRESS 002 VD Signal WEN Signal Video Signal 7.4. Pulse Width Trigger Operation (SYNC Rest Type) Input Trigger Signal Expousure Time Expousure Time Expousure Time Pulse Width Pulse Width VD Signal WEN Signal Video Signal ©2010 CIS Corporation. All rights reserved. -
Page 14: Remote Interface Function
To save the data into EEPROM, please refer to Clause 5. Function Settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2010 CIS Corporation. All rights reserved. -
Page 15: Initial Settings
Manual White Balance Not specified R-Gain Control Manual White Balance Not specified B-Gain Control Trigger Reset Mode 0: H-Synchronous Mode 75Ω Terminal Rear Panel SW(UP):75Ω Terminal ON HD/VD IN or OUT Rear Panel SW(UP):HD/VD IN ©2010 CIS Corporation. All rights reserved. -
Page 16: Ccd Optical Axis Accuracy
The center of effective pixels shall be within f 0.6 to the center of the lens mount. Datum Plane for installation *) Dimension from datum plane to the center of the lens mount 910-009-00-00 (Unit :mm) ©2010 CIS Corporation. All rights reserved. -
Page 17: Dimensions
Product Name Label *) C Mount screws comply with ANSI/ASME B1.1, 1-32UN (2B). *) Screw length from C mount lens surface shall be under 6mm. And, protruding portion shall be less than 10mm. 999-490-00-00 (Unit :mm) ©2010 CIS Corporation. All rights reserved. -
Page 18: Cases For Indemnity (Limited Warranty)
After delivery, on the rare occasion, CCD pixel defects might be noted with time of usage of the products. The cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS shall be exempted from taking responsibility on it.
