- Page 1 Instruction Manual DM-40D-BT / DM-40D-BT-W Active Monitor Speaker pioneerdj.com/support/ For FAQs and other support information for this product, visit the above site.
-
Page 2: Before You Start
Before you start How to read this manual Thank you for choosing this Pioneer DJ product. Be sure to read this manual, the “Quick Start Guide” and the “Precautions for Use” which are also included with this product. These documents include important information that you should understand before using the speakers. -
Page 3: Rear Panel
6 Pairing indicator (Page 5) a Headphone terminal When flashing: Pairing operation is performed or waiting to This is a 3.5 mm stereo mini jack type output terminal. connect Connecting headphones mutes the sound output from the When lit: Connected with a Bluetooth device speakers and outputs the sound only from the headphones. -
Page 4: Installation And Connections
Installation and connections How to install A speaker’s playback sound is delicately influenced by • The speakers should ideally be placed at an angle of 30° to conditions in the listening room. To produce optimum listening the left and right (for a total of 60°) from the listening position, conditions, take due consideration of the conditions of your and facing inward. - Page 5 CAUTION • After connecting to the terminals, lightly pull the speaker cord to make sure that heads of the speaker cord are securely connected to the terminals. A loose connection might cause audio output to be interrupted or noise to be output. • When connecting the speaker cord, thoroughly twist the core wires, and make sure that the core wires are not protruding out of the speaker terminals.
-
Page 6: Additional Information
Additional information Troubleshooting If you think something is wrong with the speakers, check the information below and refer to the [FAQ] for the DM-40D-BT at the URL below. pioneerdj.com/support/ • Inspect devices connected with the speakers. • The speakers may restore proper operation after you turn it off and on. -
Page 7: Trademarks And Registered Trademarks
When connected via Bluetooth Problem Check Measures Cannot connect or the sound is interrupted, Is there a device producing electromagnetic waves Either install the speakers away from such devices or stop using them. or unwanted noise can be heard. in the 2.4 GHz band (microwave oven, wireless LAN device, other Bluetooth device, etc.) near to the speakers? Is the distance from the Bluetooth device too far? Or... -
Page 8: Specifications
Specifications Type ................................2-Way Active Speaker Amplifier Amplifier type ................................ Class D with DSP Amplifier output ..........................Lch: 19 W / 4 Ω, Rch: 19 W / 4 Ω Input terminals (unbalanced input) ................RCA pin jacks × 1, 3.5 mm stereo mini jack × 1 Input impedance ..................................10 kΩ Output terminal ............................3.5 mm stereo mini jack × 1 Speaker Enclosure ..................................Bass reflex Enclosure material .............................. - Page 9 © 2022 AlphaTheta Corporation. All rights reserved. 6F, Yokohama i-Mark Place, 4-4-5 Minatomirai, Nishi-ku, Yokohama, Kanagawa 220-0012 JAPAN 〒220-0012 神奈川県横浜市西区みな とみ らい4丁目4番5号 横浜アイ マークプレイ ス6階 6F, Й а а i-Mark Place, 4-4-5 М а а , Н - , Й а а, Ка а а а 220-0012 ЯПОНИЯ Artemis Building, Odyssey Business Park, West End Road, South Ruislip, Middlesex, HA4 6QE, U.K.
