（⑥ of Fig.1）and power cable（③ of Fig.1）.The signal
cables can be connected to the meter through a DB9 plug.
The power cable is linked to the meter by a 2-pin plug.
The instrument front surface is divided into two parts: LCD
display window on the upper part （① of Fig.1） and
keyboard on the lower part（② of Fig.1）.

5. OPERATION INSTRUCTION

5.1 NOTES

There are two sockets on the top of the instrument as refer
to Fig.1. The right one is for signal cables，the left one is
for power cable. You should firstly insert the signal cable
and power cable into two sockets respectively when using.
The power cable has one black jaw for negative pole of
battery and one red jaw for positive pole of battery. There
are two colors: the black for signal common ground and the
red for signal input such as voltage, resistance, and
frequency, or output of simulative signal such as frequency
signal, voltage signal and voltage simulative signal of λO
sensor. The common measuring process for resistance,
voltage and frequency measure: pressing the select
function key after the signal jaw be correctly connected to
measured element.
The process for voltage and frequency signal simulation:
you have to firstly press the select function key and set the
parameter, then press the select function key again to
ensure the instrument at the simulating status, lastly
connect the signal jaws to simulation points.
Note: To avoid damaging the instrument, the above
connections must be done correctly.
