Product Detail

De vice activity LEDs
Conne ctor to De vice A
Conne ctor
to PC1
Conne ctor to PC2
DIP switch settings (located underneath switch):
SW1: Reset Switch
To re se t, O FF O N O FF
SW2 and SW3: TimeOut Setting
Time O ut is the amount of time the switch re mains locke d on a PC p ort afte r
d ata transfe r. Use a long e r Time O ut whe n conne cting to scanne rs, mass
storag e d e vice s and for larg e p rint job s.
SW2 SW3
O N O N
ON OFF
O FF O N
O FF O FF
Conne ctor to De vice B
Conne ctor to PC3
PC activity LEDs Printe r b utton
1
O N is UP. SW4 is not use d .
TimeOut
5 se cond s
10 seconds
Recommended
20 se cond s
40 se cond s
3
Conne ctor
to PC4
DC p owe r jack
(sid e )
Comp ute r b utton
ON DIP
2 3 4
