OPERATION MANUAL
NIGHT VISION SCOPE
MB-2
In USA : 3310 Prospect Ave. Cleveland, OH 44115
In Canada : 1183 Finch Ave. W., Suite 302, Toronto, ON. M3J 2G2 Canada
Tel: (416) 663-6963 Fax: (416) 663-9065
Email: NEWCONSALES@NEWCON-OPTIK.COM
NEWCON INC. 1998
Printed in Canada
Internet: www.newcon-optik.com
Advertisement
Table of Contents
Related Manuals for Newcon Optik MB-2
Summary of Contents for Newcon Optik MB-2
- Page 1 OPERATION MANUAL NIGHT VISION SCOPE MB-2 In USA : 3310 Prospect Ave. Cleveland, OH 44115 In Canada : 1183 Finch Ave. W., Suite 302, Toronto, ON. M3J 2G2 Canada Tel: (416) 663-6963 Fax: (416) 663-9065 Email: NEWCONSALES@NEWCON-OPTIK.COM NEWCON INC. 1998 Printed in Canada Internet: www.newcon-optik.com...
- Page 2 Read prior to activation You have just purchased a complicated electronic device. To operate it properly, please read this manual carefully. Here are some common Precautions that must be noted. • NEVER expose the opened objective lens of an active unit in daylight. (Note: 1st generation units will still remain active for a few minutes after switching the unit off).
- Page 3 9. ACCEPTANCE CERTIFICATE NIGHT VISION DEVICE MB-2 Serial Number _______________________________ Model MB-2_____________________ Corresponds to technical conditions ADSH 3.807.020 TU and is admitted for use. Date of production -___________________ Place for seal Quality inspector ____________________ (Signature) NEVER • connect the unit to external power sources ALWAYS •...
- Page 4 OPERATION WHEN BUYING IT. PLEASE READ ALL THE INSTRUCTIONS CAREFULLY BEFORE USING. 1. OVERVIEW MB-2 Night Vision scope is a sophisticated optico-electronic observation device designed to allow observations of personnel and orientation in nighttime conditions. The unit is utilizing an image intensifier, which amplifies available moonlight, starlight or man-made light.
- Page 5 Authorized Service. Postage, insurance, or shipping costs incurred in presenting your NEWCON product for warranty service are your responsibility. Please include a cheque or money order made out to NEWCON OPTIK for the amount of US$10.00 to cover shipping and handling.
- Page 6 -25°C (-13°F), the device must be warmed up to ambient temperature, from -20°C (-4°F) to +40°C (104°F) during 2-3 hours. Precaution MB-2 is a precision optical instrument equipped with electronics. Therefore, it should be handled with due care. • Keep your device away from direct sunlight, impacts, dust, moisture, and sudden changes of temperatures.
- Page 7 Bring the inspected object to the center of the image. Turning the eye-piece focusing lever (3) adjust to achieve the clearest image on the screen. Then obtain the most clear-cut image of the object 2. COMPONENTS MB-2 is supplied with the following components: NAME QUANTITY MB-2 N.V...
- Page 8 4, 5 1- Body Lens Focusing Ring Eye-piece Focusing Lever Switch Button for the Scope IR Illuminator Switch IR Illuminator Battery House Cover Lens Cover 9- Carrying Strap 5. OPERATION INSTRUCTIONS WARNING! NEVER OPERATE YOUR NIGHT VISION DEVICE IN DAYLIGHT AREAS WITHOUT THE LENS COVER ON ! NEVER DIRECT THE 5.1 Pre-starting procedures.
