- Page 1 Operation Manual LRB 3000PRO LASER RANGE FINDER BINOCULAR In USA: 2331 Superior Ave. Cleveland, OH 44114 In Canada: 105 Sparks Ave., Toronto, ON M2H 2S5 Newcon International ltd. © 2005-2006 Printed in Canada...
-
Page 2: Important Information
• Caution - use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous radiation exposure • Caution - the use of optical instruments such as binoculars, loupes, mirrors, lenses, etc. with this product increases eye hazard 10. QUALITY CERTIFICATE The LRB 3000PRO has passed the quality inspection. - Page 3 9. CUSTOMER SUPPORT Should you experience any difficulties with your Newcon Optik product, please consult the enclosed manual. If the problem remains unresolved, contact our customer support department at +1-416-663-6963 or toll free in North America at 1-877-368-6666. Our operating hours are 9am-5pm, Monday - Friday, Eastern Standard Time.
-
Page 4: Table Of Contents
NEWCON product for warranty service are your responsibility. Please include a check or money order made out to NEWCON OPTIK for the amount of $15.00 to cover shipping and handling. This covers products shipped in USA or Canada only. -
Page 5: Brief Description
7. TROUBLESHOOTING The range-measuring mode does not work. The display is transparent. Check whether the battery is installed properly. Check the charge of the battery. Replace it if it is weak The range-measuring mode temporarily does not work. The display indicates results of the last measurement or transparent. Wait for 8 seconds, and press the Action button again. -
Page 6: Appearance Of The Device
2. APPEARANCE OF THE DEVICE 1 – Eyepieces; 2 – Objective lens; 3 – Mode button; 4 – Action (*) button; 5 – Battery compartment cover; 6 – Rubber grip Fig. 1 6. STORAGE AND MAINTENANCE INSTRUCTIONS Precautions: LRB 3000Pro is a sophisticated precision optical instrument equipped with electronics. -
Page 7: Supplied Accessories
voltage of the primary 9-Volt battery drops below 7.2 Volts. At this point the System is still functional but the battery should be replaced as soon as possible. The System can operate at the voltage level above 7 Volt. The System remains in the active displaying state for 8 seconds after pressing of any of the operating buttons and after 8 seconds it enters the passive zero power state. -
Page 8: Technical Characteristics
4. TECHNICAL CHARACTERISTICS 1. Optics Magnification, x Objective lens diameter, mm Exit pupil diameter, mm Field of view Type of coating 2. Range Finder Type Measuring range, m Accuracy, m First, last and auto target acquisition Meters/Yards display Last 10 readings recall Reticle shape Target quality indicator 3. -
Page 9: Operation Instructions
5.4. Additional display information 5. OPERATION INSTRUCTIONS Liquid Crystal Display (LCD) The System operates in the setting Modes that are displayed as follows (refer to Fig.3): Y/M – units of distance measurement: yards or meters (3). KMH/MPH – units of speed measurement: km/hour or miles/hour (3). -
Page 10: Preparing The Device For Operation
5.1. Preparing the device for operation. • Rotate counterclockwise and open the battery compartment cover (5) located between the objective lenses (fig. 1). • Insert one 9V Ni-MH battery into the battery compartment observing correct polarity. • Close the battery compartment cover (5). •... - Page 11 • Cd12 – this mode sets the target selection to First. No other parameters of those, which were previously set, are influenced. • Cd13 – this mode sets the target selection to Auto. No other parameters of those, which were previously set, are influenced.
- Page 12 behind bushes, wires, flakes, or, opposite, measure a distance to wire, which hangs in front of the building wall. However, it cannot be guaranteed that the device will always measure the needed distance. It can happen that there will be no pulses bounced off the desired object at all.
- Page 13 If you want to leave the mode switching procedure without remembering your choice, you should press and keep held the M button for more than two seconds. This works like “Escape” key on a computer keyboard. The rangefinder will remain in the last set mode and return to the READY state.
- Page 14 Mode Screen display 1) Standard 1 Meter Select this mode Go to next mode Codes Go into submenu Go to next mode Code 1 Meter Select this mode Go to next mode Code 2 Yard Select this mode Go to next mode Code 3 Select this mode Go to next mode...
