- Page 1 USER MANUAL NDI HD hdmi sdi mini...
- Page 2 READING BEFORE USE If you find that some functions are unavailable in future use, you need to check the following to find out whether it is caused by improper operation or settings: Please use the officially designated adapter. If you cannot log in to the WebUI, please check whether the device's IP is in the same network segment as the computer's IP address, and whether the device's IP address conflicts with the IP addresses of other devices in the network segment.
-
Page 3: Table Of Contents
CONTENTS NDI® HD mini Application Topology ---------------------------------------------------- NDI® HD mini interface and indicator ---------------------------------------------------- Three ways to power on and connect to LAN ------------------------------------------------ OLED screen display instructions --------------------------------------------------------- ------------------------------------------------------------------------- Login Web UI -------------------------------------------------------------------- Device Information --------------------------------------------------------------------- Network settings -------------------------------------------------------------------- Modify the IP 7.1.1 ------------------------------------------------------------------... -
Page 4: Ndi Hd Mini Application Topology
1. NDI HD mini Application Topology NDI Encoder Application Topology Full NDI Encoder HDMI Mixing console LINE IN LINE IN External audio External audio Video Source embedding NDI Decoder Application Topology Full NDI Decoder HDMI Headset/Mic All NDI Source NDI audio and external audio De-Embeding... -
Page 5: Ndi® Hd Mini Interface And Indicator
2. NDI HD mini interface and indicator introduction SDI input:SDI signal input interface (NDI HDMI mini does not have this interface) SDI output:Encoder is looped out picture, decoder is decoded output picture (NDI HDMI mini does not have this interface) -
Page 6: Three Ways To Power On And Connect To Lan
Use USB to power on the device, and connect it to the LAN with a network cable. After startup, you will find that the character SCIENCE IMAGE Tech begins to appear on the OLED screen, and the power light on the right starts to light up. -
Page 7: Login Web Ui
First Line---NDI Encoder / NDI Decoder Displays the current NDI ® HD mini working modes: Encoding or Decoding. Second Line---NDI Source Name / Primary HDMI/SDI Selection In encoding mode, will displayed NDI stream name such as "NDI-X" that user could define this stream name on Web UI Displays the interface selected by the user's primary input, such as SDI or HDMI In decoding mode, will display NDI source which was decoding on line, alternatively display ********* if... - Page 8 Open the IE browser, enter the IP address on the OLED screen and enter the Web UI home page Default user admin admin name: Password: Method 2: Open the login page through NDI Studio Monitor The first step: Download and install the free NDI tool-NDI Studio Monitor on NewTek'sofficial website.
-
Page 9: Device Information
6. Device Information This page is the NDI® HD mini device information page, which contains the following information: Device running time (since power-on), HDMI source and SDI source of input (or the format of the decoded NDI), CPU temperature. The device information includes: Device name (can display the current codec mode of the device), device serial number, hardware version, firmware version (can be upgraded on the system page with the version update), MAC address (unique and unmodifiable), device IP address (can be Modify at any time on the web page),... -
Page 10: Dhcp Mode
There are two modes for device IP address setting: DHCP and manual. 7.1.1 DHCP mode Automatic mode (DHCP) needs to be used in the link connecting to the router. The router dynamically assigns the IP address tothe device in real time. An IP address will be randomly assigned to the device every time the power is turned on.You can log in to the webpage according to the IP address assigned by the router and modify the corresponding information (if there is no IP address assigned by the router in the link, the default IP of the device is 192.168.8.8). -
Page 11: Ndi Discovery Server Settings
7.2 NDI discovery server settings NDI discovery server can transfer video stream across network segments. To use this function, you need to use the official websiteof newtek（ https://www.ndi.tv/sdk/ Download and install NDI SDK and NDI tools.) Step 1: open NDI discovery service and record the IPv4 address of this computer (for example: 192.168.1.106). Sources represents the number of encoders connected to the server, and listeners represents the number of decoders connected to the server. -
Page 12: Ndi Multicast Settings
NDI defaults to public group. If you want to add a new group, separate it with comma ",". You can also create a separate privacy group, such as science image, so that only the device that also fills in the science image... -
Page 13: Encoder Settings
8. Encoding settings Encoder setting page can set the output format of video, stream name of video source,aspect ratio of picture, frame rate, code rate,tally light switch, NDI encoder volume and optical transceiver. 8.1 Modify the NDI stream name in the encoding state If the device is used as an encoder, you need to modify the NDI stream name. -
Page 14: Set Frame Rate
8.3 Set frame rate Support 4 kinds of frame rate settings: source frame rate, 1/2 frame rate, 1/3 frame rate, 1/4 frame rate. 8.4 Set bitrate (Bandwidth) The adjustment of bit rate can be reduced to save network bandwidth when the requirement of image quali- ty is not very high 8.5 Set up Tally lights Program and preview are both started, and software with tally (such as vmix) is used to decode the signal... -
Page 15: Intercom Switch
8.7 Intercom switch Intercom switch, click on - Application to make a call with the supporting guide software Laudo, and click off - Application to turn Open the Intercom function. 9. Decoder settings The decoder settings need to be changed in decoding mode. Please refer to page 12 for switching mode. 9.1 Set NDI decoder volume In decoding state, this page displays "set NDI decoder volume", and "decoder volume"... -
Page 16: Select Ndi Source In Decoding State
9.2 Select NDI source to decode in decoding state If this device is used as a decoder, you need to select an NDI source to decode and output.Setting steps: ① Log in to the WebUI of the decoder ② Click [Decode] ③... -
Page 17: Reset Login Password
The second is to restore all the settings on the firmware version and WebUI to the factory.To restore the factory settings, you need to power off the device, press and hold the reset key on the device from the small hole, and power on the device at the same time. -
Page 18: Firmware Upgrade
10.3 Firmware upgrade New firmware upgrades will be released regularly on the company's official website. Users can download the latest firmware to upgrade as needed. Download address:“http://www.science-image.com/EN-DOWN- LOAD/ ”After downloading, you canclick the [open upgrade page] button on the [system] page to enter the upgrade page, orclick the figure icon in the upper right corner, and then click the [firmware upgrade] button Just push the button. -
Page 19: Working Mode Switch
After the progress bar reaches 100%, the upgrade page is closed and the device restarts. Then, log in to the WebUI again and check the firmware version to check whether the upgrade is successful. During the upgrade, do not switch off the power supply or close the upgrade page. Otherwise, system files may be damaged and the system may fail to start. -
Page 20: Device Restart
10.5 Device restart Click the restart device button under the box restart control to restart the controlled device. 11. Control 11.1 Camera settings Camera type:Select the type of camera and click Connect. -
Page 21: Ptz Control Panel
Serial port baud rate:Select the baud rate of the serial port and click Apply. Camera address︓Select the camera address and click Apply. 11.2 PTZ Control Panel... -
Page 22: Briefly Introduce How To Use Vmix, Studio Monitor Software To View Ndi Video Stream
12. Briefly introduce how to use vMix and Studio Monitor software to view NDI video stream 12.1 How to use vMix to add NDI video stream and view vMix official download address: "https://www.vmix.com/software/download.aspx"Open the vMix software, click [Add Input] in the lower left corner in turn--->[NDI/Desktop Capture]---> double-click the video source you want to view... -
Page 23: How To Use Studio Monitor To View Ndi Video Stream
12.2 How to use Studio Monitor to view NDI video stream Open the Studio Monitor software, click in the upper left corner or right-click anywhere--->【SCIENCEIM- AGE】---> click the name of the NDI stream you want to view... - Page 24 Q. Why can't the device start? A. Check whether the device power indicator (located on the right side of the chassis) and OLED screen are on, and restart again with the official power adapter; Do not turn off the upgrade page and power during device upgrade!! Q.
