- Page 1 ® NDI Encoder/Decoder NDI HD mini SDI/HDMI BiDirectional NDI SDI mini NDI HDMI mini The world’s advanced NDI converter with broadcast quality. www.science-image.com Jan 2021...
- Page 2 Reading before use If you find that some functions are unavailable in future use, you need to check the following to find out whether it is caused by improper operation or settings: 1. This product is an audio and video codec conversion device, which only supports streaming and pushing in the local area network, but not on the Internet; 2.
-
Page 3: Table Of Contents
NDI® HD interface and indicator introduction 3 power-on methods of NDI HD mini OLED screen display instructions Login Web UI open the web login page log in Device Information Network settings Modify IP 6.1.1 DHCP mode 6.1.2 Manual mode NDI Multicast setting... - Page 4 Control 10.1 Setting Camera 10.2 PTZ Control How to use vMix, Studio Monitor to view NDI stream 11.1 How to use vMix to add NDI stream 11.2 How to use Studio Monitor to view NDI stream MENU www.science-image.com...
-
Page 5: Ndi® Hd Interface And Indicator Introduction
1. NDI® HD mini interface and indicator introduction 2. 3 power-on methods of NDI HD mini ① Use the standard DC-12V power supply of the product to power on, and insert the network cable to connect to the LAN; ② Power on using USB, and insert the network cable to connect to the LAN;... -
Page 6: Login Webui
4. Login webUI 4.1 open the web login page 4.2 Login In Method 1: Open the login page by entering the IP address of the device in the browser address bar.Open the computer or mobile browser, Default login account:︓admin enter the IP address displayed on the fourth line of the OLED screen of the device in the address bar, and press Enter to the login page, as shown below: Default password︓111... -
Page 7: Network Settings
6. Network Settings 6.1 Modify IP Click [Network] to enter the network setting page There are two modes for device IP address setting: DHCP and manual. 6.1.1 DHCP Mode After filling in the IP address, click the [Apply] button below, and then the system will complete the IP address modification and automatically restart the device. -
Page 8: Ndi Discovery Server Setting
NDI default public group name is: “public”, if you want to add a new group, add a comma "," to separate it. You can also create a separate private group, such as: Science Image, so that only the same fill in “Science Image”... -
Page 9: Modify The Ndi Stream Name
7.5 Set Tally Light 7.1 Modify the NDI stream name in the encoding state If the device is used as an encoder, you need to modify the NDI stream name. The NDI stream name must be unique locally, otherwise The tally light can be turned on or off at any time (there are three display states: yellow/standby, green/pre-monitoring, red/program). software such as NDI Studio Monitor may not be recognized. -
Page 10: Decoder Setting
8. Setting Decoder To change the decoder settings, the device needs to be in the decoding working mode, please refer to page 8 for working mode switching. 9. System Setting Decoder web UI 8.1 Setting Decoder volume adjusts the volume of decoding from SDI/HDMI output to the display device, such as output to monitor or TV. 9.1 Reset Password 8.2 Select NDI source to decode If this device is used as a decoder, you need to select an NDI source to decode and output. -
Page 11: Restore Initial Settings
9.2 Restoring factory settings Restoring factory settings can restore the device to its initial state, including all settings in the network, encoding, decoding, and system. Note: The firmware version will not be restored. The factory default IP address of the device is: 192.168.1.188. 9.3 Firmware Upgrade The company’s official website will regularly release new upgrade firmware, and users can download the latest firmware to upgrade as needed. -
Page 12: Working Mode Switch
10. Control Working mode switch Click [System] to enter the system setting page Select "Encoder" or "Decoder" and click the [Switch NDI Mode] button to immediately switch to the corresponding mode. If the current mode is already required, there is no need to switch. 10.1 Camera Setting The first line of the OLED screen of the product will display the working mode, "NDI Encoder"... - Page 13 10.2 PTZ Control 11.2 How to use Studio Monitor to view NDI video stream Control the zoom aperture of the camera. Open Studio Monitor software, click in the upper left corner or right-click anywhere --->【SCIENCEIMAGE】---> click the name of the NDI stream you want to view 11.
- Page 14 make better www.science-image.com ScienceImage Tech Dec 2020 www.science-image.com...
