802.11ac wave 2 dual-band enterprise access point

Advertisement

Quick Links

Quick Start Guide
802.11ac Wave 2 Dual-Band Enterprise Access Point
OAP100e
1
2
1.
OAP100e access point
2.
Mounting kit—2 brackets and 2 steel hose clamps
3.
(Optional) Mounting bracket
4.
DC Terminal plug
5.
2 x Cable glands
2
1
1.
Grounding point
2.
Console port
3.
LAN (PoE Out) port: 1Gbps connection to LAN devices
1
2
1
3
4
1
1
www.edge-core.com
3
3
4
5

Package Contents

4
5
6
6.
2 x Port covers
7.
2 x External 5G omni antennas
8.
Console cable—RJ-45 to DB-9
9.
QR code card

Overview

4.
Uplink (PoE In) port: 1Gbps uplink connection with 802.3at PoE
support
5.
DC In port: 24 Vdc
6.
5G Antenna connector
1
1.
Mounting points
2.
Enclosure for optional module
3.
LEDs:
Power: On red (power OK)
3
System: On green (power OK), Blinking (boot up)
Uplink: On amber (1Gbps link), On green (10/100Mps link),
Blinking (traffic)
LAN: On amber (1Gbps link), On green (10/100Mps link),
Blinking (traffic)
LTE: function not supported
1
2.4G: On blue (radio on), Blinking (traffic)
5G: On blue (radio on), Blinking (traffic)
4.
Reset button
– 1 –
7
8
6
9
6
E042022-MR-R01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OAP100e and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Edge-Core OAP100e

  • Page 1 Quick Start Guide 802.11ac Wave 2 Dual-Band Enterprise Access Point OAP100e Package Contents OAP100e access point 2 x Port covers Mounting kit—2 brackets and 2 steel hose clamps 2 x External 5G omni antennas (Optional) Mounting bracket Console cable—RJ-45 to DB-9...
  • Page 2 Quick Start Guide Installation Warning: For a safe and reliable installation, use only the accessories and screws provided with the device. Use of other accessories and screws could result in damage to the unit. Any damages incurred by using unapproved accessories are not covered by the warranty.
  • Page 3 Quick Start Guide (Optional) Connect a local LAN switch, computer or other device to Ground the AP the LAN (PoE Out) 1000BASE-T RJ-45 port. b. (Optional) Connect DC Power When not connected to a PoE source, wire the included DC terminal plug to a 10–24 VDC, 0.5-1 A source to provide power to the AP .
  • Page 4 Quick Start Guide Industry Canada This device contains licence-exempt transmitter(s)/receiver(s) that comply Safety and Regulatory Information with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: FCC Class B (1) This device may not cause interference. This equipment has been tested and found to comply with the limits for a (2) This device must accept any interference, including interference that Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 5 EN 60950-22: 2017 IEC 62368-1: 2014 (Second Edition) IEC 60529: 1989+AMD1: 1999+ AMD2: 2013CSV (IP55) Warranty Information and Technical Support Registering your product enables you to receive a more efficient warranty service. Be sure to register at www.edge-core.com. – 5 –...
