- Page 1 8MP H.265 IP IR Bullet Camera with 2.8-12mm Auto Focus Lens and Facial Recognition WIPX8BVAF5 Quick Start Guide Please read these instructions carefully before operating the unit and keep for further reference.
- Page 2 Intro Section Please read this instruction carefully before operating the product and keep it for further reference. All examples and pictures used here are for reference only. The contents of this manual are subject to change without notice. CAUTION: • If the product does not work properly, please contact your dealer or the nearest service centre.
-
Page 3: Table Of Contents
Contents 1.0 Introduction ......................4 1.1 Product Features ...................4 1.2 Product Dimensions ..................4 1.3 Contents ......................4 1.4 Specification ....................5 2.0 Overview ......................7 3.0 Installation ......................9 4.0 Network Connection ...................11... -
Page 4: Introduction
1.0 Introduction The Genie WIPX8BVAF5 is an 8MP IP IR bullet camera with a 2.8-12mm auto focus lens. The camera features intelligent analytics as well as facial recognition when paired with any Genie AI NVR. 1.1 Product Features • Smart H.265 / H.264 coding •... -
Page 5: Specification
Quick Start Guide 8MP H.265 IP IR Bullet Camera with 2.8-12mm Auto Focus Lens and Facial Recognition 1.4 Specification Image Sensor 1 / 2.8” CMOS Image Size 3840 x 2160 Electronic Shutter 1 / 25 s ~ 1 / 100000 s Iris Type DC Iris 0.01 Lux @ F1.2, AGC ON, 0 Lux with IR... - Page 6 Quick Start Guide 8MP H.265 IP IR Bullet Camera with 2.8-12mm Auto Focus Lens and Facial Recognition Network RJ45 Video Output CVBS output (BNC x1) Audio 1CH audio input, 1CH audio output Interface Alarm 1CH alarm input, 1CH alarm output Storage Built-in micro SD card slot, up to 256GB Hardware Reset...
-
Page 7: Overview
2.0 Overview Ethernet Connector (It is recommended to install the security cap for outdoor installation) 2. Audio Input (MIC) 3. Audio Output (HP) 4. CVBS Video Output 5. Alarm Input/Output 6. Power Connector (Can be powered by DC12V/PoE power supply. If the PoE switch is used to power the camera, DC12V power supply is not required.) Micro SD Card Slot... - Page 8 Quick Start Guide 8MP H.265 IP IR Bullet Camera with 2.8-12mm Auto Focus Lens and Facial Recognition Connecting Network Cable Loosen the nut from the main element. 2. Run the network cable (without RJ 45 connector) through both elements. Then crimp the cable with RJ 45 connector.
-
Page 9: Installation
3.0 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in and under a dry environment and place the cover of the camera within 4 hours of removing it. Drill the screw holes and the cable hole (if you want to route through the ceiling) on the wall or ceiling according to the drill template. - Page 10 Quick Start Guide 8MP H.265 IP IR Bullet Camera with 2.8-12mm Auto Focus Lens and Facial Recognition 5. Open the cover of the camera as shown in the following figure and then insert a micro SD card. After that, adjust Zoom or Focus to obtain an optimum image. Press the T or W button for Type A;...
-
Page 11: Network Connection
4.0 Network Connection Access the Camera through the IP Tool Make sure that the camera and the PC are well connected via LAN. 2. Find the IP-Tool from the CD and then install it in the computer. After that, run the IP Tool as shown below. - Page 12 Sales +44(0)1707 330541 Enquiries sales@genieproducts.co.uk Website www.genieproducts.co.uk...
