Genie WISH96 Series User Manual

Genie WISH96 Series User Manual

Wish96 series high resolution 700tvl cameras
Hide thumbs
Table of Contents

Advertisement

Quick Links

WISH96 SERIES
High Resolution 700TVL Cameras
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Genie WISH96 Series

Summary of Contents for Genie WISH96 Series

  • Page 1 WISH96 SERIES High Resolution 700TVL Cameras User Manual...
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN CAUTION RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN DO NOT REMOVE COVER(OR BACK). CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK NO USER-SERVICEABLE PARTS INSIDE.

  • Page 3: Table Of Contents

    Contents General Features ........................4 Precautions ..........................5 Safety Instructions ........................6 How to Set Up the Camera Menu .....................7 Menu Set Up ..........................10 Lens ............................11 Exposure ...........................12 White Balance ...........................14 Day & Night ..........................15 3DNR ............................16 Special ............................17 Adjust ............................21 Reset ............................21 Exit .............................21 Camera Installation ........................22 Specification ..........................25...

  • Page 4: General Features

    General Features • 700TV Lines The combination of a 960H CCD image sensor and DSP provides an excellent resolution of 700TVL • 3D-DNR Smart 3DNR prevents the image blurring of moving object and activates only if moving objects are appearing on th scene. •...

  • Page 5: Precautions

    Precautions Do not install or use the Do not install the camera Do not install the camera in camera in an environment under unstable lighting extreme temperature where the humidity is high. conditions. conditions. Only use the camera under conditions where temperatures are between -10°C and +50°C.

  • Page 6: Safety Instructions

    Safety Instructions Precautions for Use • This camera should only be installed by qualified personnel. • There are no user serviceabe parts inside. • Do not disassemble this camera other than to make initial adjustments. • Use appropriate low voltage power cable to prevent fire or electrical shock. •...

  • Page 7: How To Set Up The Camera Menu

    How to Set Up the Camera Menu Setup Menu High Resolution 700TVL Cameras...
  • Page 8 High Resolution 700TVL Cameras...
  • Page 9 High Resolution 700TVL Cameras...

  • Page 10: Menu Set Up

    Menu Set Up Menu settings can be selected using the buttons inside the camera. 1. Press the SET button. * The Set Up menu will be displayed on the monitor. SETUP LENS DCAUTO EXPOSURE WHITE BAL DAY&NIGHT COLOR 3DNR SPECIAL ADJUST RESET EXIT...

  • Page 11: Lens

    Lens This function adjusts the brightness of the image being displayed on the monitor. 1. Move the cursor to LENS using the Up and Down buttons on the Set Up menu screen. 2. Select the desired lens type by pressing the Left or Right button. SETUP LENS DCAUTO...

  • Page 12: Exposure

    Exposure 1. On the Set Up menu, Select EXPOSURE using the Up or Down buttons. SETUP LENS EXPOSURE WHITE BAL DAY&NIGHT COLOR 3DNR SPECIAL ADJUST RESET EXIT 2. Select the desired shutter mode by pressing the Left or Right button. EXPOSURE SHUTTER AUTO...
  • Page 13 • Sens Up: The degree of darkness is automatically sensed and compensated for. - Off: Deactivated status - Auto: Sens Up is in automatic mode and the gain is decided by the low luminance level. SENSE-UP SENSE-UP RETURN NOTE * Sens Up mode does not work when AGC is off. •...

  • Page 14: White Balance

    • D-WDR: This camera has 3D-DNR which provides intelligent light level control even when strong backlight is present. - Off: Deactivated status. - Indoor Compensation: To be used when the camera is installed internally. - Outdoor Compensation: To be used when the camera is installed externally. WDR OFF WDR ON •...

  • Page 15: Day & Night

    NOTE White Balance may not work correctly in the following conditions: * When there is a very high colour temperature within the subject, for example a sunset in a clear sky. * It is very dark * If the camera is pointed towards fluorescent light, or there is a drastic change in lighting, the White Balance operation may become unstable.

  • Page 16: 3Dnr

    3DNR 3DNR decreases noise caused by low luminance levels. 1. Move the cursor to 3DNR using the Up and Down buttons. 2. Select the mode using the Right or Left button. SETUP LENS EXPOSURE WHITE BAL DAY&NIGHT COLOR 3DNR SPECIAL ADJUST RESET EXIT...

  • Page 17: Special

    Special This menu is used to select additional control functions. 1. When the SETUP menu is displayed, select SPECIAL using the Up and Down buttons. 2. Select one of the modes using the Up and Down buttons. SETUP LENS EXPOSURE WHITE BAL DAY&NIGHT COLOR...
  • Page 18 • D-EFFECT: This function allows the video image to be manipulated. D-EFFECT FREEZE MIRROR D-ZOOM - - - SMART DZOOM - - - NEG.IMAGE RETURN - FREEZE: Causes the video image to freeze. - MIRROR: Causes the video image to be reversed vertically or horizontally. - D-Zoom: Implements a digital zoom of the image with x1~x32 magnification.
  • Page 19 • SMART DZOOM: This function is interlocked with D-ZOOM to distinguish specific objects in greater detail when movement is detected in programmed areas. This function is much more effective when used with optical zoom. - DIS (Digital Image Stabiliser): DIS compensates for slight image movements in the camera moves because of environmental conditions i.e.
  • Page 20 • PRIVACY: The Privacy function is used to mask certain areas of the surveillance scene. Up to 8 areas can be defined and their size is adjustable. Fifteen colours are available to differentiate areas. When RETURN is selected all changes ae saved. PRIVACY AREA AREA DISPLAY...

  • Page 21: Adjust

    Adjust This function is used to adjust the video output, and to select the type of monitor where it’s being displayed. 1. When the Set Up menu is displayed select ADJUST using the Up and Down buttons. SETUP LENS EXPOSURE WHITE BAL DAY&NIGHT COLOR...

  • Page 22: Camera Installation

    Camera Installation 1. W96BVIR TAPPING SCREW 4X25, 4EA CAMERA ASSEMBLY HEXAGON SOCKET SCREW M5X10, 4EA 2. W96BIR CAMERA ASSEMBLY TAPPING SCREW 4X20, 3EA STAND BRACKET High Resolution 700TVL Cameras...
  • Page 23 3. W96VDVIR, W96VDV BASE ASSEMBLY TAPPING SCREW 4X25, 3EA DOME COVER ASSEMBLY 4. W96VD BASE ASSEMBLY TAPPING SCREW 3.5X20, 3EA DOME COVER ASSEMBLY High Resolution 700TVL Cameras...
  • Page 24 5. W96MDVIR(W), W96MDV(W) BASE ASSEMBLY TAPPING SCREW 4X25, 3EA DOME COVER ASSEMBLY 6. W96MDW PENTAGON ANCHOR 3X25, 3EA BASE ASSEMBLY COUNTERSUNK TAPPING SCREW 4X20, 3EA DOME COVER ASSEMBLY High Resolution 700TVL Cameras...

  • Page 25: Specification

    Specification W96BVIR Model Number W96BVIR Sensor Type 1/3” Colour 960H CCD Image Sensor Effective Pixels 976 (H) x 494 (V) approx. 480K Pixels (NTSC) 976 (H) x 582 (V) approx. 570K Pixels (PAL) Total Pixels 1020 (H) x 508 (V) approx. 520K Pixels (NTSC) 1020 (H) x 596 (V) approx.
  • Page 26 Specification W96BIR Model Number W96BIR Sensor Type 1/3” Colour 960H CCD Image Sensor Effective Pixels 976 (H) x 494 (V) approx. 480K Pixels (NTSC) 976 (H) x 582 (V) approx. 570K Pixels (PAL) Total Pixels 1020 (H) x 508 (V) approx. 520K Pixels (NTSC) 1020 (H) x 596 (V) approx.
  • Page 27 Specification W96VDVIR W96VDV Model Number W96VDVIR W96VDV Sensor Type 1/3” Colour 960H CCD Image Sensor Effective Pixels 976 (H) x 494 (V) approx. 480K Pixels (NTSC) 976 (H) x 582 (V) approx. 570K Pixels (PAL) Total Pixels 1020 (H) x 508 (V) approx. 520K Pixels (NTSC) 1020 (H) x 596 (V) approx.
  • Page 28 Specification W96VD Model Number W96VD Sensor Type 1/3” Colour 960H CCD Image Sensor Effective Pixels 976 (H) x 494 (V) approx. 480K Pixels (NTSC) 976 (H) x 582 (V) approx. 570K Pixels (PAL) Total Pixels 1020 (H) x 508 (V) approx. 520K Pixels (NTSC) 1020 (H) x 596 (V) approx.
  • Page 29 Specification W96MDVIR W96MDV W96MDVIRW W96MDVW Model Number W96MDVIR / W96MDVIRW W96MDV / W96MDVW Sensor Type 1/3” Colour 960H CCD Image Sensor Effective Pixels 976 (H) x 494 (V) approx. 480K Pixels (NTSC) 976 (H) x 582 (V) approx. 570K Pixels (PAL) Total Pixels 1020 (H) x 508 (V) approx.
  • Page 30 Specification W96MDW Model Number W96MDW Sensor Type 1/3” Colour 960H CCD Image Sensor Effective Pixels 976 (H) x 494 (V) approx. 480K Pixels (NTSC) 976 (H) x 582 (V) approx. 570K Pixels (PAL) Total Pixels 1020 (H) x 508 (V) approx. 520K Pixels (NTSC) 1020 (H) x 596 (V) approx.

  • Page 31: Camera Dimensions

    Camera Dimensions 1. W96BVIR 210mm 90mm 120mm 2. W96BIR 83mm 77mm High Resolution 700TVL Cameras...
  • Page 32 Camera Dimensions 3. W96VDVIR, W96VDV 4. W96VD High Resolution 700TVL Cameras...
  • Page 33 Camera Dimensions 5. W96MDVIR(W) 6. W96MDV(W) High Resolution 700TVL Cameras...

  • Page 34: Troubleshooting

    Camera Dimensions 7. W96MDW Troubleshooting Problem Possible Cause Nothing appears on the screen. • Check the power cable, power supply output and video connection between the camera and monitor. The image on the screen is dim. • Are the camera lens or the lens glass dirty? (Clean the lens / glass with a soft clean cloth) •...
  • Page 35 High Resolution 700TVL Cameras...
  • Page 36 GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543 www.geniecctv.com Edition. GN-June 2013...

This manual is also suitable for:

W96mdwW96bvirW96birW96vdvirW96vdvW96vd ... Show all
