MiLAN MIL-185C Installation Manual

Regulatory Approvals
FCC Class A
UL 1950
CSA 22.2 No. 950
EN60950
CE
– EN55022 Class B
– EN50082-1
Canadian EMI Notice
This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
European Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the
Low Voltage Directive (73/23/EEC) issued by the commission of the European Community.
Compliance with these directives implies conformity to the following European Norms:
EN55022 (CISPR 22) - Radio Frequency Interference
EN50082-1 (IEC801-2, IEC801-3, IEC801-4) - Electromagnetic Immunity
EN60950 (IEC950) - Product Safety
Five-Year Limited Warranty
MiLAN Technology warrants to the original consumer or purchaser that each of its products,
and all components thereof, will be free from defects in material and/or workmanship for a
period of five years from the original factory shipment date. Any warranty hereunder is
extended to the original consumer or purchaser and is not assignable.
MiLAN Technology makes no express or implied warranties including, but not limited to, any
implied warranty of merchantability or fitness for a particular purpose, except as expressly set
forth in this warranty. In no event shall MiLAN Technology be liable for incidental or
consequential damages, costs, or expenses arising out of or in connection with the
performance of the product delivered hereunder. MiLAN Technology will in no case cover
damages arising out of the product being used in a negligent fashion or manner.
Trademarks:
The MiLAN logo and MiLAN Technology are registered trademarks of MiLAN Technology
in the United States and/or other countries.
To Contact Technical Support:
For prompt response when calling for service, have the following information ready:
- product serial number
- date of purchase
- vendor or place of purchase
You can reach MiLAN Technology technical support at:
- Email: support@milan.com
- Telephone: +1.408.744.2775
- Fax: +1.408.744.2793
MiAN Technology
1329 Moffett Park Drive
Sunnyvale, CA 94089
United States of America
Telephone: +1.408.744.2775
Fax: +1.408.744.2793
http://www.milan.com
info@milan.com
© Copyright 2002 MiLAN Technology Printed in the USA P/N: 90000011 Rev. G
MIL-185C/MIL-195C
ATM TWIST
ATM Fiber/UTP Converter
MIL-185C MIL-195C
500mA
5VDC
Model: MIL 185 Model: MIL 195
Ethernet
UTP
UTP UT P AC
UT P AC TI VE
TI VE to
to
Fiber
Fiber PO W
ER
ATM
ATM FI BE R
AC TI
VE
Single-Mode
Multi-Mode
10BASE-FL
CONVERTER
CONVERTER
FCC PART 15 CLASS A COMPLIANT
FCC PART 15 CLASS A COMPLIANT
TX RX

Installation Guide

This guide includes the following information:
"Introduction" on page 2
"Installation" on page 3
"Configuration Option" on page 4
"Specifications" on page 7
