- Page 2 DODGE Stealth 1991-96 / MITSUBISHI 3000GT 1991-98 Disconnect the negative battery terminal to prevent an accidental short circuit. Using a Cut and remove mounting tabs "A" and "B" panel removal tool, pry out on the radio trim on the Radio Housing. Cut and remove all bezel and remove.
- Page 3 EAGLE Talon / MITSUBISHI Eclipse PLYMOUTH Laser 1990-94 "B" Disconnect the negative battery terminal to prevent an accidental short circuit. Unclip Cut and remove all mounting tabs on the the radio trim bezel (the factory pocket will Radio Housing EXCEPT tabs "B". The be attached).
- Page 4 MITSUBISHI Diamante 1994-96 Disconnect the negative battery terminal to prevent an accidental short circuit. Remove (2) Phillips screws from each side of the gear shifter console. Remove (2) Phillips screws from the top of the console (under the ashtray). Lift the console out and remove (2) Phillips screws exposed at the base of the dash trim bezel.
- Page 5 MITSUBISHI Galant 1994-98 Disconnect the negative battery terminal to prevent an accidental short circuit. Unclip Cut and remove mounting tabs "A" and "B" the gear shifter trim panel and remove. on the Radio Housing. Cut and remove all Remove (2) Phillips screws exposed at the mounting tabs on Bracket Set #1 EXCEPT base of the dash trim bezel.
- Page 6 MITSUBISHI Montero 1992-96 Disconnect the negative battery terminal to prevent an accidental short circuit. Remove Cut and remove mounting tabs "A" and "B" (2) screws above the climate controls. on the Radio Housing. Cut and remove all Unclip the bottom of the dash trim bezel and mounting tabs on Bracket Set #1 EXCEPT remove the bezel.
-
Page 7: All Vehicles
ALL VEHICLES Fig. A Fig. C IF THE LOWER PORTION OF THE RADIO HOUSING HAS BEEN REMOVED FOR POCKET RETENTION: Mount the Brackets to the Radio Housing with (2) clips and (2) #6 x ¼" Phillips Flat-head Screws supplied. (see Fig. A) IF THE LOWER PORTION OF THE RADIO HOUSING HAS NOT BEEN REMOVED (EXCLUDING DIAMANTE and GALANT): Mount the Brackets to the Radio Housing with (4) clips and (2) #6 x ¼"... - Page 8 ¼" Fig. A Fig. C TALON 1995-98, ECLIPSE 1995-98, COLT, SUMMIT, MIRAGE, STEALTH, 3000GT, DIAMANTE, GALANT, MONTERO: No cutting of the dash or dash trim bezel is required. Skip to the Wiring Preparation in step #8. TALON, ECLIPSE, LASER 1990-94: If keeping the factory pocket is desired, cut and remove the inside half of each pocket mount located on the back of the dash trim bezel.
