Solar Cell I-V Test System (Manual)
6.
Specifications
The Solar Cell I-V Test System (Manual) specifications are shown in Table 6.1.
Table 6.1. Ossila Solar Cell I-V Test System (Manual) specifications.
Voltage range
Current range
Substrate Size
Substrate
Compatibility - T2003A
Substrate
Compatibility - T2003B
Substrate
Compatibility - T2003C
Substrate
Compatibility - T2003E
Overall Dimensions
Ossila.com
±333 µV to ±10 V
±10 nA to ±200 mA
20 mm x 15 mm or 25 mm x 25 mm
S101 (OLED substrates)
S211 (PV substrates)
S171 (Pixelated cathode substrates)
S2006 (ITO Glass Substrates – PV and OLED 25 mm Square)
Source Measure Unit: Width: 125 mm; Height: 55 mm; Depth: 185 mm
Test Board: Width: 105 mm; Height: 40 mm; Depth: 125 mm
9
User Manual
Ossila Limited © 2022
