1070 SERIES
3-SPEED CIRCULATORS
INSTRUCTION, INSTALLATION, MAINTENANCE AND REPAIR MANUAL
NOTE! To the installer: Please make sure you provide this manual to the owner of the equip ment or to the responsible
party who maintains the system.
Part # A-03-332 | © 2012 Pentair Ltd. | 11/19/12
Advertisement
Related Manuals for Pentair Aurora 1070 Series
Summary of Contents for Pentair Aurora 1070 Series
- Page 1 INSTRUCTION, INSTALLATION, MAINTENANCE AND REPAIR MANUAL NOTE! To the installer: Please make sure you provide this manual to the owner of the equip ment or to the responsible party who maintains the system. Part # A-03-332 | © 2012 Pentair Ltd. | 11/19/12...
- Page 2 SECTION 2 ITEM 1070 DATED NOVEMBER 2012 SUPERCEDES MAY 2010 1070 SERIES IMPORTANT NOTE TO INSTALLER: TERMINAL BOX: Read carefully before installing and operating the circulator. Always install the circulator with the terminal box above or beside the motor. If the terminal box is under the motor as You are about to install a pump model from the finest multi- initially mounted, remove the motor mounting screws and speed wet rotor circulator line on the market today.
- Page 3 SECTION 2 ITEM 1070 DATED NOVEMBER 2012 1070 SERIES SUPERCEDES MAY 2010 CHECK VALVE REMOVAL: Warning: 1. Insert one end of a screwdriver into the space between the Never operate the circulator dry as permanent damage may check valve and the outlet of the pump. occur.
- Page 4 SECTION 2 ITEM 1070 DATED NOVEMBER 2012 SUPERCEDES MAY 2010 1070 SERIES INSTALLATION TROUBLESHOOTING GUIDE Fault Possible Cause Remedy Noise from radiator. Excessive pressure passing the • Reduce the speed setting. Flow decreases will reduce system thermostatic valve. pressure and eliminate the noise. The radiator is not giving off The thermostatic valve is •...
- Page 5 SECTION 2 ITEM 1070 DATED NOVEMBER 2012 1070 SERIES SUPERCEDES MAY 2010 INSTALLATION TROUBLESHOOTING GUIDE – CONTINUED Fault Possible Cause Remedy Noises in system, thermostatic Pump output too high. • Reduce speed level. valves/pipes. • Open bypass/valve. • Install circuit balancing valves to adjust flow. •...
- Page 6 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 7 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 8: Warranty
WARRANTY Seller warrants equipment (and its component parts) of its own manufacture against defects in materials and workmanship under normal use and service for one (1) year from the date of installation or start-up, or for eighteen (18) months after the date of shipment, whichever occurs first.
