4.3.4.5 PROPERTIES INFORMATION
Properties information is equipment specific. The property parameters include Equipment ID, Chip
Info., Equipment Info., Site Location, Trigger Report that are equipment specified. All properties
information, in general, will be displayed in the right part of the main screen when clicking on each
node of the [Properties Info.].
There are three separate interfaces for [Properties Info.] group.
Node Name
[Equipment ID]
[Firmware Info]
[Equipment Info]
[Site Location]
[Trigger Report]
Refer to Reference 0.6.2 OMT v3.20 Software Product Manual for the specific description on
Properties Information.
RA-7800 QI
ENU Status : 1-0-1
INSTALLATION GUIDE FOR RA-7800
Description
Displays the site ID and site sub ID of the system
Displays the firmware information of the chip
Displays the equipment information as Equipment Type, Equipment Model
and Equipment Manufacture Serial Number
Displays the longitude and latitude of the equipment installation site. This
information can be viewed directly when equipment signals are connected
When using the OMT v3.20 to send a "New Site Report" command to the
Comba proprietary OMC v4.25 SP1 or above for new site installation, the
communication status between the OMT and the OMC will be indicated in this
field. It includes three statuses:
• Unreported: No [New Site Report] request is generated or new site
report failed
• Waiting: [New Site Report] request is sent out to equipment and is
waiting for the OMC response.
• Reported: The OMC succeeds in sending back "Succeed" command at
the OMT after receiving the [New Site Report] request.
Table 26: Properties information
