The figures below show the equipment enclosure layout of RA-7800 MU and RU:
RA-7800 QI
ENU Status : 1-0-1
INSTALLATION GUIDE FOR RA-7800
Fig 1: Front, side and bottom views of MU enclosure
370
DCS
WCDMA
OP/DL_UL
EXT_ALM
200-240V~50Hz/60Hz
RS-232
Fig 2: Front, side and bottom views of RU enclosure
Copyright - refer to title page
215
Page 14
