Decal Conversion Kit
Lazer Z
®
X-Series
Kit No. 116-8670
Instruction Sheet
This kit is used to replace decals on Lazer X-Series units.
Note: Visit www.exmark.com and download the French Operator's Manual that corresponds to the unit's model and serial
number.
Note: All decal locations are described from the normal operating position.
Instructions
Perform all steps shown below.
1. Verify all loose parts have been shipped.
2. Replace the decals on the unit.
3. Discard the decals from the unit.
4. Detach the Safety section and insert into Operator's manual.
1. Verify All Loose Parts Have Shipped:
Item Part No.
Description
1
93-7316
Decal-Danger
2
99-8936
Decal-Motion Control
3
106-2655
Decal-Hazard Pinched Finger
4
106-5517
Decal-Hot Surface
5
107-3069
Decal-Warning Folding ROPS
6
109-6036
Decal-Roller, Anti-Scalp
7
112-9028
Decal-Cover Missing
8
114-4465
Decal-Service Aid
9
114-4466
Decal-Fuse
10
114-4470
Decal-Height of Cut
11
116-5988
Decal-Park Brake
© 2012—Exmark Mfg. Co., Inc.
Industrial Park Box 808
Beatrice, NE 68310
Qty
Item Part No.
2
12
116-8283
2
13
116-8722
2
14
116-8724
3
15
116-8725
1
16
116-8726
1
17
116-8727
2
18
117-0346
1
19
117-3848
1
20
117-3863
1
21
117-3864
1
22
117-3888
www.Exmark.com
Form No. 4501-326 Rev A
Description
Decal-Bolt Torque
Decal-Console
Decal-Control Panel Non-EFI
Decal-Control Panel EFI
Decal-Hydro Oil
Decal-Belt Routing
Decal-Caution Fuel Vent
Decal-Warning Bagger
Decal-Wheel Torque
Decal-Fuel Fill
Decal-Slope W/ROPS
Original Instructions (EN)
All Rights Reserved *4501-326* A
Printed in the USA
Addendum
Qty
1
1
1
1
2
1
1
1
2
1
1
Advertisement
Related Manuals for Exmark Lazer Z X Series
Summary of Contents for Exmark Lazer Z X Series
- Page 1 Instruction Sheet This kit is used to replace decals on Lazer X-Series units. Note: Visit www.exmark.com and download the French Operator’s Manual that corresponds to the unit’s model and serial number. Note: All decal locations are described from the normal operating position.
- Page 2 2. Replace the Decals on the Unit: 1. Refer to the Replacement Decals table below to 3. Peel off the backing on the replacement decal to expose determine the location of the decals on the unit. the adhesive surface. Apply to a clean, dry surface and smooth to remove any air bubbles.
- Page 3 Replacement Decals (cont'd.) Front center top side of mower deck. 1-633922 109-6036 On mower deck under belt covers. 98-5954 112-9028 On rear frame on left and right sides of engine and LH rear bumper. 103-2076 106-5517...
- Page 4 Replacement Decals (cont'd.) Inside surface of upper roll bar. 107-2102 107-3069 On top left side of mower deck. 109-3148 116-8283 On motion control covers. 109-7232 99-8936...
- Page 5 Replacement Decals (cont'd.) Left side of RH console panel. 109-7330 114-4466 On RH console. 109-8483 116-8724 Under LH belt shield. 109-9361 116-8727...
- Page 6 Replacement Decals (cont'd.) On rear RH ROPS leg. 116-0090 117-0346 On LH and RH hydro guards. 116-0157 116-8726 On lower rear frame RH and LH sides. 116-0205 106-2655 On top of seat mount frame. 116-0211 114-4465...
- Page 7 Replacement Decals (cont'd.) Left side of height of cut adjustment plate. 116-0752 114-4470 On frame by fuel cap. 116-1654 117-3864 On rim of drive tires. 116-2643 117-3863 Top center of floorpan. 116-3303 117-3888...
- Page 8 Replacement Decals (cont'd.) Left side of RH motion control panel. 116-5944 116-5988 On top of seat mount frame. 109-7069 116-8722...
- Page 9 3. Discard Decals from the Unit: 1. The decals shown below, in the Decal Removal table, 2. Remove the decal and clean the surface of all residue. must be removed from the unit. No replacement decal is required. Decal Removal Location US English Decal Inside surface of upper roll bar.
- Page 10 This page is intentionally left blank.
-
Page 11: Safety And Instructional Decals
4. Detach Safety Section and Insert into Operator’s Manual: Safety Lazer Z X-Series Operator’s Manual Addendum Important: Remove the Safety page(s) from this document and insert into the Safety and Instruction Decals Section of the Operator’s manual. Safety and Instructional Decals 106-2655 1. - Page 12 112-9028 1. Warning—stay away from moving parts; keep all guards in place. 114-4465 1. Hydraulic fluid service 4. Read the Operator's interval—50 hours Manual before servicing or performing maintenance 2. Tire pressure service 5. Lubricate service interval—50 hours interval—50 hours 107-3069 3.
- Page 13 116-8724 114-4470 1. Throttle-fast 4. Choke-off 3. Locked 1. Read the Operator's 2. Throttle-slow 5. PTO Manual. 3. Choke-on 2. Height of cut 4. Unlocked 116-5988 1. Parking brake—engaged 2. Parking brake—disengaged 116-8725 1. Throttle-fast 3. PTO 2. Throttle-slow 4. Check engine 116-8283 1.
- Page 14 117-3848 1. Thrown object hazard—keep bystanders a safe distance from the machine 2. Thrown object hazard, mower-do not operate without the deflector, discharge cover or grass collection system in 116-8727 place. 3. Cutting/dismemberment of hand or foot—stay away from moving parts; keep all guards and shields in place. 117-3863 1.
- Page 15 117-3888 1. Sliding, tipping hazard—do not use the machine near drop-offs with slopes greater than 15 degrees, use the machine a safe distance form drop-offs on slopes less than 15 degrees; do not turn sharply while traveling fast, drive slowly when turning. 2.
