Cycle Country KAWASAKI Installation Manual

Winch mount kit

Advertisement

Quick Links

KAWASAKI
WINCH
MOUNT KIT
Installation
Instructions
KIT NUMBER: 25-2210
CUSTOMER MUST RECEIVE A COPY OF THIS
INSTALLATION MANUAL AT TIME OF SALE
© 2005 Cycle Country Accessories Corp.
Rev. 2
7/12/06

Advertisement

loading
Need help?

Need help?

Do you have a question about the KAWASAKI and is the answer not in the manual?

Questions and answers

Summary of Contents for Cycle Country KAWASAKI

  • Page 1 KAWASAKI WINCH MOUNT KIT Installation Instructions KIT NUMBER: 25-2210 CUSTOMER MUST RECEIVE A COPY OF THIS INSTALLATION MANUAL AT TIME OF SALE © 2005 Cycle Country Accessories Corp. Rev. 2 7/12/06...
  • Page 2 Please Note: The roller hawse, cable clamp, and cable stop are included with the winch. #25-2210 Parts List ITEM NO. QTY. PART NO. DESCRIPTION 1 CYC5173 Winch Plate 1 CYC5174 Winch Mount Weldement 4 PUR1155 5/16" x 1" Bolt 2 PUR1244 5/16" Flat Washer 4 PUR1275 5/16"...
  • Page 3 THIS WINCH MOUNTING KIT CAN BE USED TO MOUNT EITHER A CYCLE COUNTRY 1500/2500 OR A WARN 2500 TO YOUR ATV. **Some components of this kit may be already assembled. All directions referring to right and left are when the rider is sitting on the machine. Please Note: The roller hawse, cable clamp, cable stop and related hardware are included with the winch.
  • Page 4 CYCLE COUNTRY 1500 WINCH MOUNTING INSTRUCTIONS • Install the Winch Mount to the Winch Plate and the Front Bumper Frame of the ATV using two 3/8” x 1-1/4” bolts and Nylock Nuts. Do not tighten attaching hardware at this time.
  • Page 5 • Install the Winch to the Winch Mount Plate and the Front Bumper Frame of the ATV using two of the Bolts supplied with the Cycle Country Winch in the locations indicated below. The Winch Plate will not be used in this application.
  • Page 6 WARN 2500 WINCH MOUNTING INSTRUCTIONS • Install the Winch to the Winch Mount Plate and the Front Bumper Frame of the ATV using two of the Bolts supplied with the WARN Winch in the locations indicated below. The Winch Plate will not be used in this application. Be sure that when the Winch is mounted to the ATV, the Winch Motor is on the LEFT side of the machine.
  • Page 7 FAILURE TO RELEASE THE SWITCH MAY CAUSE DAMAGE TO WINCH PARTS OR TO THE ATV. When using the Winch to raise and lower a Cycle Country Plow, a Cable Stop must be installed. Hook the Winch Cable to the CYC0345 (U608) (item #4 on your 15-0001 push tube kit) through the slotted hole.
  • Page 8: One-Year Limited Warranty

    E-MAIL: ccac@cyclecountry.com ONE YEAR LIMITED WARRANTY For the period of one year from the purchase date Cycle Country Accessories Corporation will replace for the original purchaser, free of charge, any part or parts, when found, upon examination by Cycle Country Accessories Corporation, to be defective in material, workmanship, or both.
