Cycle Country 25-1161 Owner's Manual

Winch mount kit for honda atvs
Hide thumbs

Advertisement

Quick Links

Download this manual
For HONDA ATVs
OWNER'S MANUAL
MODEL NUMBER: 25-1161
CUSTOMER MUST RECEIVE A COPY OF THIS
INSTRUCTION MANUAL AT TIME OF SALE
© 2007 Cycle Country Accessories Corp.
10/9/08
Rev. B
WINCH
MOUNT KIT
1701 38TH AVE W
PO BOX 257
SPENCER, IA 51301
PHONE: 712-262-4191
FAX: 712-262-0248
SERVICE: 800-841-2222
E-MAIL: ccac@cyclecountry.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 25-1161 and is the answer not in the manual?

Questions and answers

Related Manuals for Cycle Country 25-1161

Summary of Contents for Cycle Country 25-1161

  • Page 1 PHONE: 712-262-4191 FAX: 712-262-0248 SERVICE: 800-841-2222 E-MAIL: ccac@cyclecountry.com WINCH MOUNT KIT For HONDA ATVs OWNER’S MANUAL MODEL NUMBER: 25-1161 CUSTOMER MUST RECEIVE A COPY OF THIS INSTRUCTION MANUAL AT TIME OF SALE © 2007 Cycle Country Accessories Corp. 10/9/08 Rev. B...
  • Page 2 Please Note: The roller hawse, cable clamp and cable stop are included with winch. Model Number 25-1161 Parts List ITEM NO. QTY. PART NO. DESCRIPTION 1 CYC5503 Winch Mount Plate 1 CYC5504 Roller Hawse Mount Plate 2 CYC5842 Winch Spacer 4 PUR1422 5/16"...
  • Page 3 THIS WINCH MOUNTING KIT CAN BE USED TO MOUNT EITHER A CYCLE COUNTRY 1500/2500 WINCH OR A WARN 1.5/15RT-XT/25RT-XT WINCH All directions referring to right and left are when the rider is sitting on the machine. The roller hawse, cable clamp, cable stop, and hardware are included with the winch.
  • Page 4 3. Remove mesh radiator grill. See picture below. 4. Place the four 5/16” x 1-1/8” x 2-1/4” square U-bolts (Item 3) over the top of the bumper support braces. Insert the winch mount plate (Item 1) under the bottom of the bumper support braces with the center slots to the right side of the ATV.
  • Page 5 CYCLE COUNTRY 1500 WINCH MOUNTING INSTRUCTIONS I. TRX 500 FA Rubicon 4x4: Insert the Winch with the motor facing to the LEFT through the opening shown. (Note: The radiator mesh grill was removed to allow clearance for this step. Do not allow the winch to come in contact with the radiator or damage to the radiator may occur).
  • Page 6 8x40 bolts (Item 8), two flatwashers (Item 6) and two lock nuts (Item 7) will not be used. Tighten at this time. IV. GO TO ROLLER HAWSE INSTRUCTION ON PAGE 8. CYCLE COUNTRY 2500 WINCH/WARN 2500 WINCH MOUNTING INSTRUCTIONS I. TRX 500 FA Rubicon 4x4: Insert the winch with the motor facing to the RIGHT through the opening shown.
  • Page 7 Set the winch onto the roller hawse mount plate, aligning the holes on the three components, and using the four bolts PROVIDED WITH THE CYCLE COUNTRY WINCH, fasten them together. The two spacers, four 8x40 bolts, four 5/16” x 1-1/2” bolts, four flatwashers, and four nylock nuts, will not be used.
  • Page 8 WARN 1.5/15RT-XT/25RT-XT WINCH MOUNTING INSTRUCTIONS • Install winch spacers (Item 3) when using these Warn winches. • Install the spacers between the winch and the roller hawse mount plate as shown on parts list. Orient the spacers with the longest gap to the mount hole to the front. •...
  • Page 9 FAILURE TO RELEASE THE SWITCH MAY CAUSE DAMAGE TO WINCH PARTS OR TO THE ATV. When using the Winch to raise and lower a Cycle Country Plow, a Cable Stop must be installed. Hook the Winch Cable to the CYC0345 (U608) (item #4 on your 15-0001 push tube kit) through the slotted hole.

  • Page 10: One-Year Limited Warranty

    E-MAIL: ccac@cyclecountry.com ONE YEAR LIMITED WARRANTY For the period of one year from the purchase date Cycle Country Accessories Corporation will replace for the original purchaser, free of charge, any part or parts, when found, upon examination by Cycle Country Accessories Corporation, to be defective in material, workmanship, or both.
  • Page 11 If a winch is what you must have, then you’ve come to the right place: 1500lb, 2500lb and 3000lb Winches We also have an extensive line of winch mounts for both Cycle Country and Warn winches If you need to haul more gear on your quad, check out our baskets:...
