Cycle Country 25-5193 Assembly & Owners Manual

Winch mount kit for yamaha utvs
Hide thumbs

Advertisement

Quick Links

Download this manual
1701 38TH AVE W
PO BOX 257
SPENCER, IA 51301
PHONE: 712-262-4191
FAX: 712-262-0248
SERVICE: 800-841-2222
E-MAIL: ccac@cyclecountry.com
www.cyclecountry.com
WINCH
MOUNT KIT
For YAMAHA UTVs
ASSEMBLY / OWNER'S
MANUAL
MODEL NUMBER: 25-5193
© 2010 Cycle Country Accessories Corp.
10/14/10
MAN0120
Rev. 01

Advertisement

loading
Need help?

Need help?

Do you have a question about the 25-5193 and is the answer not in the manual?

Questions and answers

Related Manuals for Cycle Country 25-5193

Summary of Contents for Cycle Country 25-5193

  • Page 1 1701 38TH AVE W PO BOX 257 SPENCER, IA 51301 PHONE: 712-262-4191 FAX: 712-262-0248 SERVICE: 800-841-2222 E-MAIL: ccac@cyclecountry.com www.cyclecountry.com WINCH MOUNT KIT For YAMAHA UTVs ASSEMBLY / OWNER’S MANUAL MODEL NUMBER: 25-5193 © 2010 Cycle Country Accessories Corp. 10/14/10 MAN0120 Rev. 01...
  • Page 3 THIS WINCH MOUNTING KIT CAN BE USED TO MOUNT EITHER CYCLE COUNTRY WINCHES OR OTHER AFTERMARKET WINCHES TO YOUR UTV. Please Note:  All directions referring to right and left are when the rider is sitting on the machine. ...
  • Page 4 MODEL NUMBER 25-5193 WINCH MOUNT INSTALLATION INSTRUCTIONS 1. Remove the front grill on the UTV and remove or loosen bottom skid plate. 2. Place the winch mount inside of the front UTV grill and align the two outside holes on the winch mount with the two existing holes on the UTV frame.
  • Page 5 3. For all winches other than 4000 lb. : (If using a 4000 lb. winch, go to instructions on page 7) Place the roller hawse mount plate on the inside of the tubing and on top of the winch mount. Attach the roller hawse mount plate to the winch mount at the outer holes with two 3/8”...
  • Page 6 2-BOLT WINCH MOUNTING INSTRUCTIONS  Be sure that when the winch is mounted to the UTV, the winch motor is on the LEFT side of the machine. Align the two holes on the winch up to the two slotted holes on the winch mount and attach with 5/16” x 1” bolts, flatwashers and nylock nuts.
  • Page 7 4000 LB. WINCH MOUNTING INSTRUCTIONS  Be sure that when the winch is mounted to the UTV the winch motor is on the RIGHT side of the machine. Align the winch and the roller hawse mount plate that came with the winch, with the holes noted on drawing below and attach the winch with the four bolts provided with the winch.
  • Page 8 Tighten all attaching hardware at this time. 6. Re-install front grill of ATV.
  • Page 9 CYCLE COUNTRY WINCH SWITCH MOUNTING INSTRUCTIONS: NOTE: Other winch manufacturers may require a different assembly process or alternate hardware to attach switch to the bracket.  To mount the winch switch, remove the auxiliary switch bracket (A) and place the winch switch inside the switch mount bracket. Align the two holes of the winch switch mount bracket with the mounting holes in the switch.

  • Page 10: One-Year Limited Warranty

    ONE YEAR LIMITED WARRANTY For the period of one year from the purchase date Cycle Country Accessories Corporation will replace for the original purchaser, free of charge, any part or parts, when found, upon examination by Cycle Country Accessories Corporation, to be defective in material, workmanship, or both.
