Lightolier Calculite HID Lensed Adjustable Accent C4MRW Specification Sheet

Page 1 of 2
6" min.*
6 1/2" max.
Ceiling Cutout: 5 1/16" (129 mm) Dia.
Reflector Trim
C4MRW CLW Specular Clear, White Flange
C4MRW CLP Specular Clear, Polished Flange C4LVMU
C4MRW
Add suffix. See options for
other finishes.
Note: Magnetic transformers may produce audible sound when used with
dimmers, which may be objectionable in acoustically critical areas.
Features
1. Aperture Cone: 16 ga. aluminum. Slot cut cone opening minimizes view into
fixture. Keyed to lampholder assembly for true aiming of lamp thru aperture
center and to prevent incorrect installation of cone. Hinged, and snaps onto
adjustable lampholder for easy tool-less installation. Available with painted
white or polished flange. Interchangeable with other Evolution 4 1/2" low
voltage trims.
2. Lampholder Assembly: Die-cast aluminum. Built-in aperture shield blocks
view into fixture. 45° vertical tilt (35° max. with remodel frame-in kit), 360°
horizontal rotation are tensioned to hold position. Hot aiming is possible
using a phillips screwdriver. Matte black finish. Lamp shield keeps interior of
fixture dark.
3. Lamp Support: Die-formed aluminum with knurled surface for easy gripping
during relamping. Spring tension clips hold lamp and lens and allow fast
snap-in, snap-out relamping. Matte black finish. Accepts up to two 2" dia.
accessories.
4. Cover Glass: High temperature, tempered glass. Precisely contours to fit
onto cone; replaceable.
5. Vertical /Horizontal Locking: Single screw adjustment; independent
locking system.
6. Socket Harness: Porcelain bi-pin socket. Pre-wired with No. 18 Teflon
7. Power Harness: Provides power to transformer.
8. Frame-In Kit: Compatible frame-In kits are listed above.
Non-IC and Non-IC AirSeal
and wiring compartments and must not be placed above fixture in a manner
which will entrap heat.
IC-Airseal - Fixture may be in direct contact with insulation.
®
9. Maximum Ceiling Thickness: .875", 1.75" with C4TCA2 accessory
(see C4TCA2 specification sheet for details.)
Lightolier is a Philips group brand
C4ALV
9 5/8"
(245mm)
5" (127mm)
14 3/8"
(365mm)
5 1 4
7
5 1/4"
•
4 1/8" Dia.
5 1/2" Dia.
Frame-In Kit
Non-IC 120V/277V
C4LVE1
C4LVE2
42-75W
MR16(12V)
- Insulation must be kept 3" away from fixture sides
®
Calculite Evolution Lensed Adjustable
®
4 1/2" Aperture MR16 Lensed Adjustable Accent Reflector Trim
C4LV
C4AICLV
10 1/8"
(257mm)
12 5/8"
(321mm)
11 3/16"
5" (127mm)
(284mm)
22 3/8"
14 3/8"
(568mm)
(365mm)
2 3 5 6 8
•
•
.875" Max. Ceiling Thk.
Non-IC AirSeal
C4ALVMU Magnetic 120/277V
Magnetic 120/277V
Electronic 120V C4ALVE1 Electronic 120V
Electronic 277V 42-75W
MR16(12V)
Remodel Frame-In Kit
Non-IC 120V
C4LVE1RM 50W Max.
MR16 (12V)
Options & Accessories
Reflector Finishes
Clear: CL
Comfort Clear Diffuse:
Specify desired flange: W White, P Polished For 30° Bias cut cone, add suffix
1
"30".
Evolution 4" Trims with Non-IC Frames
C4MRW 1 Secondary Color Lens or 1 Mixing Color Lens and 1 Specialty Filter
Labels
CULUS Listed (suitable for wet locations), I.B.E.W.
Teflon is a registered trademark of E.I. DuPont.
®
US Patent No. 5,957,573. Other US and Foreign Patents Pending.
Job Information
Job Name:
Cat. No.:
leads.
®
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • F0708
14 5/8"
(372mm)
9" (229mm)
9 1/4"
C4MRW / C4AICLV
120V/277V IC AirSeal 120V
® ®
C4AICLVM1
C4AICLVE1
20-50W
MR16(12V)
See separate specification sheet
for more information
1
Gold: GD White: WH Black:
CCD Champagne Bronze:
Type:
C4MRW
Magnetic 120V
Electronic 120V
BK
CCZ
