GO-SOUND 12-15Air User manual
10) Echo
It adjust the Echo level on MIC IN 1 and 2 and to VHF MIC1 e 2. It has no effect on LINE
input and MP3 player.
11) Digital Media Player
This panel controls all functions related to the multi-player and hosts the BT receiver
as well as USB and SD-Card slots. For further information about how to use it, see "4.2.
Digital Media Player & Go-Sound Air App" on page 12.
12) Media Player Level
This controls the overall signal level of the Digital Media Player (MP3/BT/SD-Card).
13) Master Level
This controls the overall level of the speaker.
NOTE: It doesn't affect the MIX OUT level.
14) Mix Out
It is a stereo RCA output with unbalanced line-level signals. It contains the mix of all
inputs and all controls. It can be used for recording purposes or simply to connect
the GO-SOUND Air PA system to a mixer o any other audio system. This output is not
controlled by MASTER LEVEL.
15) Power and Clip Led
When power cord is connected to the AC power connector and POWER switch is ON,
the green LED "POWER" lights.
The CLIP indicator (RED LED) only lights up when the input signal is too high and the
limiter works to prevent unwanted damage to the amplifier and the transducers.
NOTE: to better adjust the levels and to prevent the limiter from operating
and consequently cutting the signals, once the desired sound source is con-
nected, slowly increase the levels 8, 9, 12 and MASTER LEVEL (13) until the
desired volume is reached taking care, the CLIP indicator lights up occasion-
ally. Always protect your hearing if you are near when the loudspeaker rings
at high volume.
16) 5-Band Graphic EQ
This EQ optimizes the overall frequency response in order to better adapt the speaker
to the environment in which it is used. It operates on 5-bands (100Hz, 330Hz, 1KHz,
3,3KHz, 10KHz) and with a gain/reduction of +/- 12dB.
17) Battery Level Status
When you connect the power cable, you can check battery charge (even without
switching the unit on) basing on the number of LEDs that are on. When charge level is
below 25%, the red LED flashes and indicates that you need to re-charge the battery
as soon as possible. For further details battery and charge function, please refer to "7.
ENGLISH
11
