Promate PM1100i Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operator Manual
PM2100i
PM1100i
PORTABLE INVERTER GENERATOR
Degree of Protection: IP23
IMPORTANT – Please make certain that persons who are to use this
equipment thoroughly read and understand these instructions and any
additional instructions provided prior to operation.
Record the model and serial numbers of your Generator below:
Model No._____________________ Serial No._______________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM1100i and is the answer not in the manual?

Questions and answers

Related Manuals for Promate PM1100i

Summary of Contents for Promate PM1100i

  • Page 1 Operator Manual PM2100i PM1100i PORTABLE INVERTER GENERATOR Degree of Protection: IP23 IMPORTANT – Please make certain that persons who are to use this equipment thoroughly read and understand these instructions and any additional instructions provided prior to operation. Record the model and serial numbers of your Generator below:...

  • Page 2: Table Of Contents

    Due to constant efforts to improve our products, certain procedures and specifications are subject to change without notice, if you have any questions, please contact Promate Service. CONTENTS Safety Precautions...

  • Page 3: Safety Precautions

    1. Safety Precautions The electric power generated by the gasoline engine of the generator can be used for many kinds of electric appliances. When handling it, please keep to the following matters. Please make sure you review each precaution carefully. EXHAUST PRECAUTIONS OTHER SAFETY PRECAUTIONS •...

  • Page 4: Controls And Features

    2. Controls and Features Read this owner's manual before operating your generator. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Generator PM1100i PM2100i Carrying Handle Spark Plug Access Cover Fuel Lever Vent...
  • Page 5 Control Panel PM1100i PM2100i Notice: Total power drawn from all receptacles must not exceed the name plate rating. 1. Ground Terminal 7. Low Oil Warning Indicator Light 2. 1 x 12V DC Outlet 8. Economic Control Switch 3. 230V Duplex 9.

  • Page 6: Before Starting

    When Adding Fuel Remove the fuel fill cap and clean the area around it. Slowly add UNLEADED fuel to the fuel tank. PM1100i PM2100i Install the fuel cap and wipe up any spilled gasoline cleanly before starting the engine. Remove oil fill cap/dipstick to add oil.

  • Page 7: Operation

    • from windows, doors, and vents, to reduce the risk carbon monoxide from potentially PM1100i PM2100i accumulating towards occupied spaces. • Install battery-operated carbon monoxide alarms. Push the engine switch to the “ON” position. Smoke alarms cannot detect carbon monoxide gas.

  • Page 8: Economy Control Switch

    When using the DC output, turn the Eco- Throttle switch to the "OFF" position. Do not start the vehicle while the battery charging PM1100i PM2100i cable is connected and the generator is running. The vehicle or the generator may be damaged.
  • Page 9 To prolong the life of your generator and attached The overload indicator light will turn on when the devices, follow these steps to add electrical load: load exceeds 900W (for PM1100i), or 1600W (for Start the generator with no electrical load PM2100i). If the load exceeds 1000W (for attached.

  • Page 10: Maintenance And Storage

    5. MAINTENANCE AND STORAGE Oil Cont’d The owner/operator is responsible for all periodic maintenance. Never operate a damaged or defective generator. Tampering with the factory set governor will avoid your warranty. Spark Plugs Improper maintenance will avoid your warranty. Maintenance, replacement, or repair of emission control devices and systems may be performed by any non-road engine repair establishment or individual.

  • Page 11: Cleaning

    Clean around air intake and muffler Every 8 hours or daily Change oil Every 8 hours or daily Clean air filter PM1100i PM2100i Change oil if operating under heavy load or in hot environments 1. Remove the maintenance cover. Every 8 hours or daily Change oil 2.

  • Page 12: Service And Storage

    Use a soft bristle brush to remove dirt and oil. Use an air compressor (25 PSI) to clear dirt and We recommend using a fuel stabilizer. A fuel debris from the generator. stabilizer will minimize the formulation of fuel Inspect all air vents and cooling slots to ensure gum deposits during storage.

  • Page 13: Specifications

    6. SPECIFICATIONS PM2100i PM1100i Engine Specification Engine Specification Displacement………………………………………. 50cc Displacement………………………………………. 80cc Type………………………………………. 4-stroke O HV Type………………………………………. 4-stroke O HV Start Type…………………………………………. Recoil Start Type…………………………………………. Recoil Generator Specifications Generator Specifications Rated Power…………………………………… 900 Watts Rated Power…………………………………… 1600 Watts Maximum Power………………………… 1000 Watts Maximum Power……………………………...

  • Page 14: Troubleshooting

    7. TROUBLESHOOTING Problem Cause Solution No fuel Add fuel Faulty spark plug Replace spark plug Generator will not start Unit loaded during start up Remove load from unit Fill crankcase to the proper level Low oil level Place generator on a flat, level surface Generator starts but runs roughly Choke in the wrong position.

  • Page 15: Service Information

    Company's prior authorization. To order replacement parts and consumable • Consumable parts such as battery, spark parts, please contact Promate Service (details plugs, and air cleaner. below) and be ready with the following information: Warranty Period: One (1) year from the date 1.

  • Page 16: Generator Exploded View

    Parts Diagram: Promate PM1100i...
  • Page 17 Parts List: Promate PM1100i Alias Description Note GB6177 M4 NUT M4 GB5789 M6X15 FLG. BOLT M6 y 15 ST02FD-05302007 OVERLOAD PROTECTOR (10A) 0910.200604.30 MOUNT RUBBER BASE SETTING GB5783 M5X14 NUT M5 y 14 GB61177.1 m6 NUT M6 GB6170 M2 NUT M2 0910.200601.30...
  • Page 18 Engine Parts Diagram: Promate PM1100i...
  • Page 19 Engine Parts List: Promate PM1100i Alias Description Note 12.020000.01 OIL SEAL 0910.030036.20 BOARD GB845 ST4.8X16 SELF-TAPPING SCREW ST4. 8X16 0910.030007.00 COVER, CRANKCASE 0910.190006.00 RUBBER, END COVER 139FMD-1001001 PIN DAWL 0910.190003.00 GENERATOR END COVER 0910.030035.00 OIL NOZZLE GB5789 M6X12 FLG. BOLT M6X12 0910.031000.00...
  • Page 20 Parts Diagram: Promate PM2100i...
  • Page 21 Parts List: Promate PM2100i Alias Description Note 0902.200502.20 FUEL GUIDE PLATE 0902.200500.20 COVER, TOP GB818 M5X14 03 SCREW M5X14 0902.200300.20 RIGHT SIDE COVER ASSY. (RAL9005) 0902.200612.20 PASSAGEWAY, AIR CLEANER 0902.200613.20 PASSAGEWAY, ELECTRIC MACHINERY 02.006002.00 NUT M6 0902.200600.20 BASE ASSY. (RAL9005)
  • Page 22 Engine Parts Diagram: Promate PM2100i...
  • Page 23 Engine Parts List: Promate PM2100i Alias Description Note 0902.081001.00 MUFF. PROTECTOR SEAL GB6177.1 M6 03 GB5789 M6X12 BOLTE M6X12 0902.020001.00 BREATHER PIPE 0902.061000.20 STARTER ASSY. 0902.021000.20 CYL. HEAD COVER ASSY. GB5789 M6X15 BOLT M6X15 0902.020002.00 CYLINDER COVER GASKET 02.006001.00 0902.080200.00 AIR SHROUD CYLINDER COMP.
